limited lifetime consumer warranty Directed Electronics ("Directed") promises to the original purchaser to repair or replace with a comparable reconditioned model any Directed unit (hereafter the "unit"), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the lifetime of the vehicle provided the following conditions are met: the unit was professionally installed and serviced by an authorized Directed dealer;...
OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages.
BlackJax 5 module and harness PlainView2 switch High Output Siren important information Congratulations on the purchase of your state-of-the-art vehicle anti-carjacking and vehicle recovery system. It has been designed to provide years of trouble-free operation. This system must be installed by an authorized dealer.
your warranty Your warranty registration must be completely filled out and returned within 10 days of purchase. Your product warranty will not be validat- ed if your warranty registration is not returned. Make sure you receive the warranty registration from your dealer. It is also necessary to keep your proof of purchase, which reflects that the product was installed by an authorized dealer.
Page 8
Sounds siren and flashes lights less than one minute later Thief can’t restart the engine, even if he could remove the BlackJax 5 system Ignores any PIN code guesses of the thief after three incor- rect entries (resets to allow PIN entry after a predetermined...
BlackJax 5 provides a safe and effective means of recovering your vehi- cle after a theft or carjacking. In a carjacking situation, the sooner you are out of the car the better. Don’t resist or take anything with you, just get out and get away.
— siren wailing and lights flashing — the carjacker has no choice but to abandon your car. (The same occurs to anyone who steals your parked car from you at a gas station or in a parking lot, which are the most common carjacking sites).
entering a code To enter your code, press the times on the PlainView 2 switch, followed by the a zero, you simply press the EXAMPLE 1: To enter the factory set code of 2, you would press and re lease the switch in this manner: EXAMPLE 2: To enter a code of 1230, you would press: –(1), and then...
PIN code Since all BlackJax 5 systems use the same factory-set code of 2, we strongly recommend that you program your own unique code as soon as possible.
Page 13
3. Within 5-seconds, press and release the you count, you will hear a chirp each time you press the After 7 presses, immediately press the enter your new code. Refer to the code examples described in Entering a Code section. 4.
BlackJax 5 is not a car alarm, but you can set BlackJax 5 to automati- cally immobilize your vehicle’s starter and ignition systems to prevent a thief from starting the engine if he breaks into your parked car. This will assure that he will not even be able to drive your car off at all.
turning autoimmobilization feature on/off 1. Enter program mode by turning on the ignition, entering your PIN code, then pressing and holding the button of the PlainView 2 switch for 3-seconds until you hear a chirp. 2. Press the button once, then pause. After pausing, you will hear a confirmation chirp.
LED status indicator LED Status System is disarmed and in normal operating mode (i.e., valet mode is off). Valet mode is on (i.e., BlackJax anti-carjacking is off). The vehicle may be driven without ever having to enter the PIN code. Flashing Rapidly Anti-carjacking mode has been engaged, enter (ignition On)
changing siren duration 1. Enter program mode by turning on the ignition, entering your PIN code, then pressing and holding the button of the PlainView 2 switch for 3-seconds until you hear a chirp. 2. Press the blank button once, then pause. After pausing, you will hear a confirmation chirp.
optional cliffNet wizard™ & dataport interface connector With the free CliffNet Wizard software and an optional CliffNet Replicator (p/n 905265), you can plug your Windows PC into your Clifford system to program the features mentioned previously: CliffNet Wizard will show you, on your PC screen, all your user-pro- grammable feature settings.
health check Directed Electronics recommends you return to your installing Clifford dealer to have your system checked for correct operation. The first check is due one year after the installation date and at yearly intervals thereafter. n n o o t t e e : : There may be a small charge incurred for this service.
Page 20
The company behind this system is Directed Electronics. Since its inception, Directed Electronics has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, Directed is ISO 9001 registered.
