OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
This manual provides information for:
MODELS
BPM-15/30/40G(CE)
ECLIPSE™ ERGONOMIC
TILTING BRAISING PAN
· Stainless Steel
· Manual Tilt
· Gas Heated
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE.
READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND
WARNINGS CONTAINED IN THIS MANUAL.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
POST IN A PROMINENT LOCATION
Instructions to be followed in the event user smells gas.
This information shall be obtained by consulting your
local gas supplier. As a minimum, turn off the gas and
call your gas company and your authorized service
agent. Evacuate all personnel from the area.
WARNING
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, injury or
death. Read the installation, operating and maintenance
instructions thoroughly before installing or servicing this
equipment.
NOTIFY CARRIER OF DAMAGE AT ONCE
It is the responsibility of the consignee to inspect the container upon receipt of
same and to determine the possibility of any damage, including concealed dam-
age. Unified Brands suggests that if you are suspicious of damage to make a
notation on the delivery receipt. It will be the responsibility of the consignee to file
a claim with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
PART NUMBER 160812, REV. H (02/15)
International
1055 Mendell Davis Drive
Jackson, MS 39272
888-994-7636, fax 888-864-7636
unifiedbrands.net
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Groen BPM-15G
Summary of Contents for Groen BPM-15G
- Page 1 OPERATOR MANUAL IMPORTANT INFORMATION, KEEP FOR OPERATOR This manual provides information for: MODELS BPM-15/30/40G(CE) International ECLIPSE™ ERGONOMIC TILTING BRAISING PAN · Stainless Steel · Manual Tilt · Gas Heated THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL.
-
Page 2: Important Operator Warnings
IMPORTANT - READ FIRST - IMPORTANT THESE APPLIANCES MUST BE INSTALLED BY A COMPETENT PERSON IN CONFORMITY WITH THE INSTALLATION AND SERVICING INSTRUCTIONS AND NATIONAL REGULATIONS IN FORCE AT THE TIME. PARTICULAR ATTENTION MUST BE PAID TO THE FOLLOWING: I. E. E. REGULATIONS FOR ELECTRICAL INSTALLATIONS ELECTRICITY AT WORK REGULATIONS GAS SAFETY (INSTALLATION &... - Page 3 CLOSE THE MAIN GAS COCK. ALLOW FIVE MINUTES FOR UNBURNED GAS TO VENT. FAILURE TO DISCONNECT COULD RESULT IN ELECTROCUTION AND DEATH. CAUTION: USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY GROEN OR AUTHORIZED DISTRIBUTORS CAN CAUSE INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND WILL VOID ALL WARRANTIES.
-
Page 4: Table Of Contents
Table of Contents Important Operator Warnings ............page 2-3 References..................page 4 Equipment Description............... page 5-6 Inspection and Unpacking ............page 7 Installation ................page 8-11 Assembly and Commissioning ..........page 11-13 Servicing and Conversion ............. page 14-19 User Instructions ..............page 20-21 Cleaning.................. -
Page 5: Equipment Description
Equipment Description Groen gas-heated Eclipse Ergonomic Tilting Braising Pans provide a stainless steel pan equipped with patented heat transfer fins, burner/combustion chamber, hand- operated or electric powered tilting mechanism, thermostatic controls, and hinged cover. The appliance serves as braising pan, griddle, fry pan, oven, kettle, bainmarie and food warmer/server, can be adapted for use as a non-pressure steamer and can be used to stir-fry, reheat and saute foods. - Page 6 Equipment Description Optional equipment available with these models are: Fill faucet with swing spout (left or right mounted) - specify single or double pantry Fill faucet with 48” or 60” spray hose assembly (left or right mounted) - specify single or double pantry Caster mounting kit Flanged feet 2”...
-
Page 7: Inspection And Unpacking
Inspection & Unpacking CAUTION The unit will arrive completely assembled, wrapped in protective plastic on a heavy skid, SHIPPING STRAPS ARE UNDER TENSION in a heavy cardboard carton. Immediately upon receipt, inspect the carton for damage. AND CAN SNAP BACK WHEN CUT. Report any apparent shipping damage or an incorrect shipment to the delivery agent. -
Page 8: Installation
Installation CAUTION The following information pertains to the CE model BPM-G, and replaces or augments INSTALLER MUST VERIFY THAT THE the information provided in OM-BPM. These appliances must be installed by a INSTALLATION COMPLIES WITH THE competent person in conformity with the installation and servicing instructions and APPLICABLE LOCAL CODES AND national regulations in force at the time. - Page 9 Installation Ventilation Rate Required EQUIPMENT For a unit on casters, the installation shall be made with a connector that complies with the standard for Connectors for Moveable Gas Appliances, m³/min ft³/min ANSI Z21.69 - CSA 6.16. Restrain movement of the unit by attaching a Range, Unit Type cable or chain to the eyelet provided at the back of the frame and anchor Pastry Oven...
- Page 10 Pressure Adjustments for model BPM-G (CE) using natural (G20) and propane (G31) gas sources. Total Gas Rate Natural Natural BTU/ Propane Propane Model (G20) KW (G31) KW BTU/hr BPM-15G 16.3 55,700 16.3 55,700 BPM-30G 26.1 89,100 26.1 89,100 BPM-40G 36.1 123,300 36.1...
-
Page 11: Assembly And Commissioning
Installation Burner Adjustment The burner primary airflow may be adjusted by loosening the screw and sliding the aerator forward or backward. (See photograph) Gas is connected at the rear of the control console. Fig. 3 Fig. 4 Assembly & Commissioning WARNING Electrical Supply THIS APPLIANCE MUST BE EARTHED. - Page 12 Assembly & Commissioning WARNING Operating the Braising Pan THIS APPLIANCE MUST BE EARTHED. Lighting Sequence Put water in the pan (6 to 12 mm deep) Check that gas and electricity mains are on. Turn the toggle switch (Main Control Box) to the “ON” position. The power lamp (green) (Main Control Box) will illuminate.
- Page 13 Assembly & Commissioning WARNING If the unit fails to operate as described, the unit should be serviced by DO NOT OVERFILL WITH OIL OR an Engineer. FIRE MAY RESULT! Instructions to Installer IMPORTANT: After installing and commissioning the appliance, the User’s Instructions should be handed to the user or purchaser.
-
Page 14: Servicing And Conversion
When any threaded gas connection is disturbed for any reason, the threads must be resealed with appropriate gas leak prevention sealant that is suitable for the type of gas. Unified Brands/ Groen recommends gas sealant compound such as Locktite® 243 or Unified Brands part number 122002. - Page 15 Servicing & Conversion To change the type of gas used (e.g G20 to G31 or inverse) following parts should be changed: Burner injectors. See instruction Paragraph 13 on the following pages. Igniter tube injector. This is inserted inside the igniter tube as shown at left. Gas valve spring.
- Page 16 Servicing & Conversion Removal of Tilt Switch (Turn gas and electricity mains off) Remove electical panel cover and control as described in Paragraph 3-A & 3-B. Disconnect electrical leads from tilt switch (See Fig. 11). Remove screws holding the tilt switch. Withdraw the tilt switch from control compartment.
- Page 17 Servicing & Conversion To Calibrate: (If calibration is required) Fill the pan with unused oil to the indicated mark. Place a thermocouple 25 mm below the oil surface in the middle of the pan. Remove the control knob and place a screwdriver down the centre of the spindle.
- Page 18 Servicing & Conversion 11. Removal of Burners (Turn gas and electricity mains off) Undo and remove the front two retaining nuts of the burner guard. Undo the two retaining nuts at the side of the burner guard. Do not fully remove.
-
Page 19: Servicing And Conversion
Servicing & Conversion Wiring Diagram, BPM-30G & BPM-40G Models OM-BPM-G... -
Page 20: User Instructions
User Instructions Lighting and Operation Check that gas and electricity mains are on. Turn the toggle switch (Main Control Box) to the “ON” position. The power lamp (green) (Main Control Box) will illuminate. Turn the thermostat (Upper Control Box) to the desired setting. Observe that the burners light by the lighting of the heat lamp (amber) WARNING (Main Control Box) (approximately 10-15 seconds). - Page 21 User Instructions WARNING In addition to the gas lockout, other safety features include: HI LIMIT RESET SHOULD BE USED A high limit safety thermostat which cuts off the gas supply should SPARINGLY TO COMPLETE AN ONGOING the operating thermostat fail (i.e., should the temperature exceed COOKING OPERATION.
-
Page 22: Cleaning
If there is difficulty removing mineral deposits or a film left by hard water or food residues, clean the pan thoroughly and then use a deliming agent, such as Groen De-limer/De-Scaler (P/N 140513), in accordance with the manufacturer’s directions. Rinse and drain the unit before further use. -
Page 23: Safety Precautions
Safety Precautions A stop-cock will be fitted in the gas pipe supplying the appliance. The user must be familiar with its location and operation, and able to turn it off in an emergency. If there is a smell of gas, immediately turn off the gas, ventilate the area, and call the gas supplier. NEVER USE NAKED FLAME TO SEARCH FOR GAS LEAKS. -
Page 24: Troubleshooting
Your Groen braising pan will operate smoothly and efficiently if properly maintained. However, the following is a list of checks to make in the event of a problem. If the actions suggested do not solve the problem, call your qualified Groen Service Representative. -
Page 25: Troubleshooting
Troubleshooting SYMPTOM WHAT TO CHECK (X indicates work that should only be performed by a qualified service representative) System does not produce Authorized a. Thermostat, and close the contacts if they are open X a spark. Service Rep Only b. AC voltage between terminals on secondary side of transformer. If it is not 24 Volt, replace the transformer X c. -
Page 26: Schematics/Parts Lists
Parts List Stand & Foot Assembly Description Part # CASTER KIT (SET OF 2 WITH 146354 BRAKE AND 2 W/O BRAKE) CASTER WITH BRAKE (W/O 146513 FOOT ADAPTER) CASTER WITHOUT BRAKE 146515 (W/O FOOT ADAPTER) NOT SHOWN FOOT ADAPTER 146516 FLANGED FOOT 146521 (W/O FOOT ADAPTER) - Page 27 Parts List Cover & Counterbalance Assemblies Key Qty Description Part # COVER ASSEMBLY, 15 171217 GALLON COVER ASSEMBLY, 30 160861 GALLON COVER ASSEMBLY, 40 160808 GALLON COUNTERBALANCE 162235 ASSEMBLY, 15 GALLON COUNTERBALANCE 145480 ASSEMBLY, 30 GALLON COUNTERBALANCE 144790 ASSEMBLY, 40 GALLON WELD STUD, 1/4-20 X 012589 1-1/4"...
- Page 28 Parts List Gas Piping Assemblies Key Qty Description Part # U BOLT 1/2” PIPE N70636 WASHER PLAIN 1/4 005472 NUT HEXAGON KEPS NT1101 1/4-20 SERR./ZINC ELBOW 90 DEG 1/2 NPT 008747 NIPPLE 1/2 NPT X 003229 10-1/2” IGNITION MODULE PLATE ASSY 160775 ELECTRONIC IGNITION SWIVEL JOINT 1/2 NPT...
- Page 29 Parts List Combustion Chamber & Gas Manifold Assemblies Key Qty Description Part # Key Qty Description Part # COMBUSTION CHAMBER BURNER ORIFICE, 30 155706 146148 ASSY, 15 GAL. GAL., PROPANE COMBUSTION CHAMBER BURNER ORIFICE, 40 145941 128158 ASSY, 30 GAL. GAL., NATURAL GAS COMBUSTION CHAMBER 144843...
- Page 30 Parts List Electrical Control Components - Gas OM-BPM-G...
- Page 31 Parts List Electrical Control Components - Gas Key Qty Description Part # FUSE HOLDER MAIN CONTROLS 077854 FUSE -24VAC CONTROL, 3A, TYPE AG 077853 SCREW, ROUND HEAD #8-32 X 1-1/4” 005056 SCREW, ROUND HEAD #6-32 X 3/8” 009697 SCREW, HEX SLOTTED HD #8-32 X 3/8” 069789 TILT SWITCH BRACKET WELD ASSY.
- Page 32 160801 TERMINAL BLOCK BOX 146205 ELECTRICAL PANEL 146129 COVER ASSY PANEL REAR HEAT SHIELD, BPM-30G (NOT 150621 SHOWN) PANEL REAR HEAT SHIELD, BPM-15G (NOT 162211 SHOWN) PANEL REAR HEAT SHIELD, BPM-40G (NOT 150622 SHOWN) COVER GASKET (NOT 64” 145662 SHOWN)
- Page 33 Parts List Manual Tilt Assembly Key Qty Description Part # GEAR CARRIER 002624 SHAFT, HANDWHEEL 144834 GEAR, WORM 128001 GEAR SECTOR 009829 KEY GIB 012031 HANDWHEEL 012061 PIN ROLL 012614 SCREW SET SOCKET 012060 BEARING ROLLER 002790 BEARING SLEEVE 137239 PLUG PIPE 010286 FITTING GREASE 90...
- Page 34 Parts List Fuel Gas Conversion (For conversion of a natural gas unit to propane or a propane model to natural gas) BPM WITH ELECTRONIC IGNITION Description Natural Gas LP Gas Part # Part # PILOT ORIFICE 119449 098647 BURNER ORIFICE 128158 146148 IGNITION TUBE ORIFICE 40 GAL.
-
Page 35: Service Log
Service Log Model No: Purchased From: Serial No: Location: Date Purchased: Date Installed: Purchase Order No: For Service Call: Date Maintenance Performed Performed By OM-BPM-G... - Page 36 1055 Mendell Davis Drive • Jackson MS 39272 888-994-7636 • 601-372-3903 • Fax 888-864-7636 unifiedbrands.net PART NUMBER 160812, REV. H (02/15) © 2015 Unified Brands. All Rights Reserved. Unified Brands is a wholly-owned subsidiary of Dover Corporation.
