2.2 Reader Stand Installation
Step1. Align and insert a reader stand to the fixture
holes at the back of a reader
2.3 Installation Notice
Do not place the reader on a metallic surface to avoid interferences
3
LED Indicator
There are 4 LED indicators on a QProx. From left to right are blue, orange, green and red color LEDs
Status Description of LED Indicators
The states of the LED indicators are described below:
After QProx is initialized and ready for transaction, the blue LED will light up.
The blue LED indicates the reader is ready for contactless card transactions
The blue and yellow LED indicate that a card has been detected and the
transaction process is started.
The blue, yellow and green LED indicate a SUCCESSFUL transaction.
The red LED indicates transaction FAILURE or malfunction.
4
Contactless Card Landing Zone
The Land Zone icon is printed on the center of working area, which indicates the
correct location to detect user's card.
Step2. Push the reader stand upward until hearing
a click sound
