- Page 1 VEGA9300 User’s Manual V0.3 Version: 0.3 Date: July 20,2005 Castles Technology Co., LTD. Tel: 886 (2) 8913-1771 Fax: 886 (2) 8913-1772 E-Mail: casauto@casauto.com.tw Web: www.casauto.com.tw © Castles Technology Co., LTD. 2004 All rights reserved...
-
Page 2: Warning
Castles Technology Co., LTD. All trademarks mentioned are proprietary of their respective owners. -
Page 3: Table Of Contents
Magnetic Stripe Card Reader & Smart Card Introduction ...7 Handset and the Base Connection ..........8 1.6.1 Pull Out ................8 1.6.2 Pull Back ................8 Rechargeable Battery Installation..........8 SAM Card Installation..............9 Paper Roll Installation...............10 1.10 Power ..................11 3/11 Castles Technology Co., Ltd. All rights reserved. -
Page 4: Introduction
Back To The Program Manger Screen. F2 Key、F3 Key：Press F2 or F3 Key To Select The Program When There Are Many Applications In The Program Manager Screen. F4 Key：Press F4 To Execute The Selected Program. Castles Technology Co., Ltd. All rights reserved. 4/11... -
Page 5: Side View
LAN：RJ45, Only Provide In VEGA 9320 Model Phone Line Switch：With RJ11 Cord，All Data Can Be Received By Build-In Fast Modem In VEGA9300 Series. There Are 2 Port One Is Line Another Is Tel For Connect To Telephone. Castles Technology Co., Ltd. All rights reserved. -
Page 6: Back View
VEGA9300 User's Manual V0.3 1.4 Back View Rechargeable Batter Cover Rechargeable Battery Cover 4 SAM Slots Rechargeable Battery Box Open The Rechargeable Battery Cover, Release The Rechargeable Battery Box For Inserting The SAM Card Castles Technology Co., Ltd. All rights reserved. 6/11... -
Page 7: Magnetic Stripe Card Reader & Smart Card Introduction
Base Power LED Magnetic Stripe Card Should Be Placed On Card Reading Slot With Magnetic Stripe Facing Left, Swipe The Card From Top To The Bottom. Insert User IC Card With Chip Facing Up. Castles Technology Co., Ltd. All rights reserved. 7/11... -
Page 8: Handset And The Base Connection
< 25mΩ) Caution：Please Turn On Both The Power Of The Handset And The Base To Charge The Battery Automatically. Dangerous：Do Not Use The Normal Battery (Non-Rechargeable Battery) Which May Damage The Device. Castles Technology Co., Ltd. All rights reserved. 8/11... -
Page 9: Sam Card Installation
Turn To The Left To Open 2. Place The SAM Card To The Upper Position With Chip Facing Down As The Below Picture 3. Close Down The Case And Push Forward To Lock Castles Technology Co., Ltd. All rights reserved. 9/11... -
Page 10: Paper Roll Installation
VEGA9300 User's Manual V0.3 1.9 Paper Roll Installation Insert The Paper Roll To The Box And Pull The Paper Down As The Picture. Close The Paper Roll Box To Start Paper Loading. Castles Technology Co., Ltd. All rights reserved. 10/11... -
Page 11: Power
VEGA9300 User's Manual V0.3 1.10 Power Please Connect With The Attached DC 12V Adapter. Input : 100 ~ 240 Vac, 50 ~ 60Hz , 1.8A Max. Output : 12Vdc, 3.3A Castles Technology Co., Ltd. All rights reserved. 11/11...
