- Page 1 Getting started with your Castles V3M2 Portable...
- Page 2 What’s in the box Thank you for ordering the Castles V3M2 Portable payment terminal. In the box you will find: Box 1 • Wi-Fi Access Point • Power Supply • LAN (Ethernet) cable Box 2 • Power supply • Charging dock •...
- Page 3 Setting up Wi-Fi access point Step 1 Connect the ethernet cable into the blue WAN Port. Step 2 Plug the other end of the cable into the internet source such as a router. Step 3 Connect the power supply to the Wi-Fi Access Point and connect the power socket to the power outlet and turn it on.
- Page 4 Setting up your terminal Step 1 Connect the USB cable to power adaptor. Step 2 Once the power supply is connected to the power outlet, connect the micro-USB to the terminal. Step 3 Turn the power outlet ON and the orange power light will come on showing the terminal is charging.
- Page 5 Charging dock setup Step 1 Place the charging dock on a soft surface with the back facing up. Step 2 Lift the cable tidy. Step 3 Connect the power cable into the DC 9V port and the power supply to the power outlet. Step 4 The green power indicator will appear when the charging dock is receiving power.
- Page 6 Install the till roll Step 1 Pull upwards on the lever located in the middle of the printer door. Step 2 Place the till roll in the compartment. The paper must feed from underneath the roll. Step 3 Close the printer door.
- Page 7 How to take a payment Step 1 power button Press and hold the (above the red key) until the screen lights up. The terminal will power on and initialise for use. Step 2 ‘enter amount’ When the screen is displayed, attempt a test transaction with your own payment card.
