Installation instructions

Please follow the installation steps below to ensure your appliance operates correctly.
Dimensions and clearances
• The cooker must be installed no less than 50 mm away from any side walls which exceed the height of the
cooktop.
• The cabinetry surrounding the cooker must be made of heat-resistant material and must be able to withstand
temperatures of 65 °C above room temperature.
• Do not install the cooker near flammable materials (eg curtains).
• If you stand the cooker on a pedestal, make sure you provide safety measures to keep it in place.
https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SDBSIPX1/User_Guide_OR90SDBSIPX1/02_Install
Updated: Wed, 27 Mar 2019 03:09:12 GMT
Powered by
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the OR90SDBSIPX1 and is the answer not in the manual?

Questions and answers

Related Manuals for Fisher & Paykel OR90SDBSIPX1

Summary of Contents for Fisher & Paykel OR90SDBSIPX1

  • Page 1: Installation Instructions

    • Do not install the cooker near flammable materials (eg curtains). • If you stand the cooker on a pedestal, make sure you provide safety measures to keep it in place. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SDBSIPX1/User_Guide_OR90SDBSIPX1/02_Install Updated: Wed, 27 Mar 2019 03:09:12 GMT Powered by...
  • Page 2 Locating the area for electrical connection Fig. 1 Area for electrical connection Fig. 2 Dimensions and distances from cooker https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SDBSIPX1/User_Guide_OR90SDBSIPX1/02_Install Updated: Wed, 27 Mar 2019 03:09:12 GMT Powered by...
  • Page 3 • Note: nuts are supplied with the cooker in a separate kit. Do not refit the kickstrip until you have installed the Fig. 3a Screw/unscrew the feet to get the required anti-tip bracket. height https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SDBSIPX1/User_Guide_OR90SDBSIPX1/02_Install Updated: Wed, 27 Mar 2019 03:09:12 GMT Powered by...

  • Page 4: Fitting The Anti-Tilt Bracket

    Fig. 5 Accessing the anti-tilt bracket by removing the b. Press the lever of the left guide rail down and drawer pull the lever of the right guide rail up. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SDBSIPX1/User_Guide_OR90SDBSIPX1/02_Install Updated: Wed, 27 Mar 2019 03:09:12 GMT Powered by...
  • Page 5 Gently push the drawer in completely; the safety catches will automatically hook. 7. Replace the kickstrip using the two screws. Beware of sharp edges when removing or replacing the drawer. Fig. 7 Replacing the drawer https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SDBSIPX1/User_Guide_OR90SDBSIPX1/02_Install Updated: Wed, 27 Mar 2019 03:09:12 GMT Powered by...
  • Page 6 Take extra care not to damage the door sensor (top left of oven). Fig. 8 Correctly lifting the cooker Fig. 10 Incorrectly moving the cooker Fig. 9 Incorrectly lifting the cooker https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SDBSIPX1/User_Guide_OR90SDBSIPX1/02_Install Updated: Wed, 27 Mar 2019 03:09:12 GMT Powered by...

  • Page 7: Fixing The Backguard

    5. Strain the feeder cable and block it with cable clamp ‘E’ (by screwing screw ‘D’). 6. Close the terminal block cover (check the two hooks ‘A’ are correctly hooked). https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SDBSIPX1/User_Guide_OR90SDBSIPX1/02_Install Updated: Wed, 27 Mar 2019 03:09:12 GMT Powered by...
  • Page 8 WARNING: If the power supply cable is damaged, it must be replaced only by an authorised service agent in order to avoid a hazard. Voltage and power consumption 220-240/380-415 V 3N~ 50 Hz 47.2A (230V) 10850 W (diversity not applied) Fig. 12 Terminal block https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SDBSIPX1/User_Guide_OR90SDBSIPX1/02_Install Updated: Wed, 27 Mar 2019 03:09:12 GMT Powered by...
  • Page 9 * Connection with wall box connection. • Diversity factor applied. • A diversity factor may be applied to the total loading of the appliance only by a suitably qualified person. https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SDBSIPX1/User_Guide_OR90SDBSIPX1/02_Install Updated: Wed, 27 Mar 2019 03:09:12 GMT Powered by...

  • Page 10: Electric Diagram Key

    SI Oven bottom heating element (int.) R Product relay SF State functions SE Oven bottom heating element (ext.) M Terminal block DL Door lock device CI Oven circular heating element T Earth Connection https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SDBSIPX1/User_Guide_OR90SDBSIPX1/02_Install Updated: Wed, 27 Mar 2019 03:09:12 GMT Powered by...
  • Page 11 DS Door sensor IU-LH Induction unit, left zones R1 Relay 1 IU-RH Induction unit, right zones https://producthelp.fisherpaykel.com/nz/Cook/Freestanding_Cookers/Induction/OR90SDBSIPX1/User_Guide_OR90SDBSIPX1/02_Install Updated: Wed, 27 Mar 2019 03:09:12 GMT Powered by...
