Weiser Smartcode 10 Installation And User Manual page 2

3 Install the exterior touchscreen
A
What is the diameter of the hole in the door?
Diameter is 2-1/8"
(54 mm)
or
2-1/8"
54 mm
"D" is required for installation. "D" is not needed for
Install "D" on "F". installation. Discard "D".
F
D
B
Locate screws for step 3C and keep them within reach.
T
4 Install the interior assembly
A
Remove battery cover and battery pack from interior assembly.
a
Make sure turnpiece is in
the vertical position.
c
Make sure
turnpiece shaft is
rotated as shown.
L
5 Install the batteries and perform the door handing process
This step will teach your lock the orientation of your door and is crucial to lock operation.
A
Install 4 AA batteries in battery pack.
W
K
Ensure correct polarity.
For best results, use
new, non-rechargeable
Alkaline batteries only.
All manuals and user guides at all-guides.com
C
Install exterior touchscreen and mounting plate.
Diameter is 1-1/2" a
(38 mm)
1-1/2"
38 mm
D
c
screws evenly.
b
L
M
d
K
Do not install
batteries until step 5.
Alarm will sound if
battery is installed
before cable is
L
connected.
B
Make sure the door is open, and
insert the battery pack.
K
2 / 4
b
F
Cable goes
underneath latch.
d
Keep parallel to
edge of door.
T
T (2x)
Tighten
B
Install interior assembly onto mounting plate.
a
L
align
Ensure tight cable
connection.
c
C
After a few seconds, the latch bolt will retract and extend on
its own to learn the orientation of the door. This is called the
door handing process, and it is crucial to lock operation.
D
If the touchscreen indicates a failure, attempt this procedure again.
If the door handing process is still unsuccessful after a second
attempt, consult the Programming and Troubleshooting Guide on
the SmartCode 10 Touchscreen page at www.weiserlock.com.
Support exterior
assembly during
mounting plate
installation.
G
Route cable through
center hole, then push
cable into bottom hole.
E
Insert key and
test latch. If latch
does not extend or
retract smoothly,
adjust screws (T).
Remove key when
finished and make
sure the latch bolt
is fully extended.
b
Lay excess cable flat inside the
bottom of the interior housing.
d
U
(2x)
Once the door handing process
is complete, the touchscreen
will indicate success or failure:
Success: Failure:
flashing checkmark flashing
symbol and single "X" pattern
column of digits
