Hayward ColorLogic 4.0 Installation Manual page 12

Configuring Lights
After all lights are found, each light will need to be assigned an identification number. These
numbers will be shown as LT1,LT2, LT3..., depending on how many lights are found. The
number will identify the light for all future programming of shows, colors, etc.
The light being assigned will blink The message below will be
Step N Step O
to help identify the specific light. displayed if key presses are made
prior to the module storing the
To change the light #, press the + or
previous information. Simply wait a
– button. Then press the right arrow
moment and try again.
button to assign the next light.
Page 10
