UCL Series Underwater
Small Lighting Niche
for ColorLogic
IMPORTANT SAFETY INSTRUCTIONS
Basic safety precautions should always be followed, including the following: Failure to follow instructions can
cause severe injury and/or death.
This is the safety-alert symbol. When you see this symbol on your equipment or in this manual, look for
one of the following signal words and be alert to the potential for personal injury.
WARNING warns about hazards that could cause serious personal injury, death or major property dam-
age and if ignored presents a potential hazard.
CAUTION warns about hazards that will or can cause minor or moderate personal injury and/or property
damage and if ignored presents a potential hazard. It can also make consumers aware of actions that are
unpredictable and unsafe.
The NOTICE label indicates special instructions that are important but not related to hazards.
and CrystaLogic
®
Owner's Manual
LGGUY1000
Hayward Pool Products
620 Division Street, Elizabeth NJ 07207
www.hayward.com
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Pool/Spa lights
TM
Contents
Light Warnings................2
Introduction....................3
Important Information.....3
Installation.....................4
Replacement Parts..........6
General Warnings...........7
Warranty.........................9
Registration Card...........10
IS0801A RevC
