Boundary Plus® Mode Operation:
In Boundary Plus mode, your pet's Computer Collar® Unit will activate as your pet crosses over
The Shields® Gate transmitter. This patented technology allows you to position the transmitter in a
doorway to prevent entry into a room without impeding your pet's movement near the transmitter.
Ensure the BOUNDARY/SHIELDS switch is in the Boundary Plus position.

• Adjust Signal Field Range

o Determine the desired location and the signal field range required.
• Wireless: 10 inch minimum up to 28 inch maximum signal field height.
• Signal field should be set to activate your pet's Computer Collar® 10 to 16 inches above
where sits on your pet's neck.
o With the unit ON, press the RANGE UP (+) or the RANGE DOWN (-) buttons to increase
or decrease the signal field range. The first indicator equals 10 inches of signal field. Each
additional number represents approximately 4 inches of range.

• Verify Signal Field Range

o Holding the Computer Collar 10 to 16 inches above the height as it sits on your pet's
neck, start from the "In Bounds Side" of the transmitter and move slowly towards
the "Out of Bounds Side" of the Shields Gate transmitter. The Out of Bounds Side is
indicated by the charge jack. Do not touch the correction posts at this time.
o The Computer Collar Unit will beep as it crosses over the transmitter. The beeping will be
accompanied by a correction.
o If the Computer Collar fails to beep, increase the signal field until activation occurs.
DISPLAY
1
2
3
4
5
Charge Jack
APPROX. HEIGHT
10
14
18
23
28
IN BOUNDS SIDE
OUT OF BOUNDS SIDE
InvisibleFence.com
9
