Safe Dog
Monitor
Installation and Training Manual
Rev. 1.0 JAB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Safe Dog Monitor and is the answer not in the manual?

Questions and answers

Related Manuals for INVISIBLE FENCE Safe Dog Monitor

Summary of Contents for INVISIBLE FENCE Safe Dog Monitor

  • Page 1 ® Safe Dog Monitor Installation and Training Manual Rev. 1.0 JAB...

  • Page 2: Table Of Contents

    4.3.1 Alert Notification Email 4.3.2 Example of Alert Notification Email 4.3.3 Alert Notification Schedule 4.4 LED Status Indicator Lights 5.0 Safe Dog Monitor Registration Rev. 1.0 JAB G:\PCTEST LAB\2006 Reports\TRP\Safe Dog Monitor - Part 68\TCB Documents\KZ3-050808 manual.doc Need Part Number...
  • Page 3 - DRAFT - 5.1 Registration Process 5.1.1 Pre-registration 5.1.2 Registration – Before Installation 5.1.3 Registration – After Installation Rev. 1.0 JAB G:\PCTEST LAB\2006 Reports\TRP\Safe Dog Monitor - Part 68\TCB Documents\KZ3-050808 manual.doc Need Part Number...

  • Page 4: Product Introduction

    Fence Brand transmitter and detect when a change occurs in signal amplitude – specifically, the detection of a wire break condition. The Safe Dog Monitor will also detect an increase or decrease in the signal amplitude and an RF Link Communication failure between the Loop Sensor and Dialer Unit.

  • Page 5: Loop Sensor User Control

    Sensor via a 900 MHz radio frequency signal. If an alert condition is detected, the Dialer Unit initiates an alert notification to Invisible Fence, Inc. This alert notification is then sent via email to the appropriate Invisible Fence Brand Distributor and Dealer.

  • Page 6: Safe Dog Monitor Dialer Unit

    3.0 Safe Dog Monitor Installation Process Please read the entire installation process before attempting to install the Safe Dog Monitor. Pay careful attention to the sequence of the steps. 3.1 Programming the Safe Dog Monitor Loop Sensor and Dialer Unit RF Link Programming of the Loop Sensor and Dialer Unit is critical to proper operation of the Safe Dog Monitor.

  • Page 7: Safe Dog Monitor Loop Sensor

    3.2.4 Connecting AC Power Power to the Loop Sensor is supplied by the AC adapter used to power the Invisible Fence Brand transmitter. A Y-adapter included in the Safe Dog Monitor system pack (SPSDM-100) or in the Safe Dog Monitor repair kit (RK-28) is used to provide power to both the transmitter and Loop Sensor.

  • Page 8: Calibrating The Signal Field To The Loop Sensor

    Connect the Dialer to a working phone jack. There are two available phone jack connectors on the Dialer Unit. Either connector can be used for connecting the Dialer Unit to the wall mounted phone Rev. 1.0 JAB G:\PCTEST LAB\2006 Reports\TRP\Safe Dog Monitor - Part 68\TCB Documents\KZ3-050808 manual.doc Need Part Number...

  • Page 9: Successful Rf Communication Link

    [Show picture of Dialer unit base, pointing out mounting holes] 3.3.6 Using Battery Back-up Battery back-up is also available via a standard 9V alkaline battery. If the Safe Dog Monitor Loop Sensor is connected to the 12v lead acid battery back-up, the Dialer Unit should also use the battery back-up option to ensure communication if there is a loss of power.

  • Page 10: Alert Conditions

    When an alert condition is detected, the Dialer Unit initiates an alert notification call to Invisible Fence, Inc. The Dialer Unit’s serial number and the alert code will be transmitted. Upon receipt of this information, Invisible Fence, Inc. will send a notification email to the appropriate Dealer and Distributor.
  • Page 11 - DRAFT - 5. Alert code The above information will only be transmitted to the Dealer and Distributor if the Safe Dog Monitor Registration process is completed. Review section 5.0 for instructions on completing the registration process. Rev. 1.0 JAB G:\PCTEST LAB\2006 Reports\TRP\Safe Dog Monitor - Part 68\TCB Documents\KZ3-050808 manual.doc...

  • Page 12: Example Of Alert Notification Email

    7045064001112 0xF1 4.4.3 Alert Notification Schedule § The Safe Dog Monitor will continue to send alert notifications to the Dealer and Distributor until the alert condition has been resolved at the installation. 4.5 LED Status Indicator Lights The LED status indicator can be used to identify the status of either the Loop Sensor or Dialer Unit.

  • Page 13: Safe Dog Monitor Registration

    5.0 Safe Dog Monitor Registration The main purpose of the Safe Dog Monitor is to provide proactive customer service in the event of an alert condition. Therefore, completion of the Safe Dog Monitor Registration process is critical to providing the highest level of customer service.
  • Page 14 If “kitting” of customer system components is not done, the registration of the Safe Dog Monitor must be done after installation. During the installation, the serial number of the Dialer must be recorded for entry into the Safe Dog Monitor warranty database. This can be done on the installation contract of installation checklist.
  • Page 15 RJ11C. If trouble is experienced with this equipment, for repair or warranty information, please contact your Invisible Fence Brand Professional. If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required.
