Summary of Contents for INVISIBLE FENCE Shields Gate
- Page 1 Invisible Fence Indoor Solutions Shields® Gate Owner’s Manual InvisibleFence.com...
-
Page 2: Important Precautions
Accordingly, if a customer has reason to believe that their pet may pose a danger to others, or harm itself, the customer should not rely solely upon the Invisible Fence system to keep the pet from crossing the boundary. - Page 3 Invisible Fence dealer or visit us at InvisibleFence.com. This device is not designed to operate as a containment transmitter. • Important: To ensure your pet does not receive an unintended correction, make sure your pet is not wearing the Computer Collar® Unit when turning ON or adjusting The Shields Gate transmitter. InvisibleFence.com...
-
Page 4: Table Of Contents
Multi-Area Avoidance .......................... 10 Programming the Computer Collar® Unit ..................10 Linking Multiple Shields Gate Units Together ................11 Training Guide ..............................11-13 For Pets trained to the Invisible Fence® Outdoor Pet Containment System ..........................11 For Pets New to Invisible Fence .......................12 Troubleshooting ..............................13 Battery Disposal ............................... -
Page 5: Components
One on the top side of the unit for turning the unit ON and OFF during normal use. AC Adapter The AC adapter (RAC00-13701) is intended for long-term use or for recharging the Shields Gate transmitter. Use the AC adapter to charge the battery pack for a minimum of 4 hours prior to first use. -
Page 6: Operating Guide
• Battery life of approximately 30 days can be expected from a fully charged battery. • The Shields Gate transmitter will give an audible chirp once every 30 seconds and the power button will flash red every 5 seconds when the battery is low and charging is required. -
Page 7: Control Panel
7K/10K FREQ – System frequency set by Invisible Fence® dealer. o ON/OFF MOTION – Turns motion sensing on or off. “On” mode allows your Shields Gate to go into a sleep mode that wakes as it detects motion to save battery life. -
Page 8: Adjust Signal Field Range
Locate the switch for the Channel (A), Channel (B) and (A+B) Channel. o Select the desired channel setting. Note: Shields Gate will not enter into programming mode if the switch is set to A+B. See Programming Computer Collar on Page 10 o Adjust and verify signal field range. -
Page 9: Boundary Plus® System Operation
“In Bounds Side” of the transmitter and move slowly towards the “Out of Bounds Side” of the Shields Gate transmitter. The Out of Bounds Side is indicated by the charge jack. Do not touch the correction posts at this time. -
Page 10: Multi-Area Avoidance
Computer Collar begins to flash green. • The Computer Collar is now programmed to the desired channel. • Verify operation by turning ON Shields Gate and moving the Computer Collar into the signal field. You will hear the Computer Collar beep when it activates. -
Page 11: Linking Multiple Shields Gate Units Together
The units will work in a linked configuration whereas the first unit in the chain controls signal field range and motion sensing. Please contact your local Invisible Fence® Brand dealer to find out if the linking option is right for you and to obtain the required hardware. -
Page 12: For Pets New To Invisible Fence
If your new Shields® Gate system is used to keep only specific pets out of a specific area, an enhanced visual cue will need to be created. For example, if Shields Gate is meant to keep your dog away from your litter box, flagging the area would also deter the cat who have been trained to understand the meanings of the flags. -
Page 13: Troubleshooting
Ensure the Computer Collar is set to same Shields Gate sound warning CHANNEL setting. See Multi-Area Shielding Section on page 10. beep Need additional help? Contact your local Invisible Fence dealer. Call 1-800-578-3647 or visit InvisibleFence.com to find your local dealer. InvisibleFence.com... -
Page 14: Battery Disposal
If you no longer require this equipment, do not place it in the normal municipal waste system. Please return it to where it was purchased in order that it can be placed in our recycling system. If this is not possible, please contact your local Invisible Fence dealer. InvisibleFence.com... -
Page 15: Compliance
Compliance US and Canada FCC ID: KE3-3002769 This device complies with Industry Canada rules. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 16 Dealer Name_________________________________ Dealer Phone_________________________________ System Frequency____________________________ Notes: ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ 800-578-3647 (USA) (865) 777-5404 (International) ©2017 Radio System Corporation All rights reserved. Protected by Patents: U.S.: 7,046,152; 7,068,174; 7,204,204; InvisibleFence.com...
