Alco‐Sensor FST®


The Alco‐Sensor FST® has an automatic sampling system designed to ensure that a sample of
deep lung air is obtained and analyzed. In order to trigger automatic sampling the subject must
blow  with  a  minimum  flow  rate,  must  produce  a  minimum  breath  volume  and  blow  for  a
minimum  duration.    When  the  minimum  flow  rate  is  met  a  continuous  tone  will  sound,  the
head  icon  will  stop  flashing,  the  message  Blow  will  disappear,  and  one  of  three  progressive
dashes will appear to the right of the icon. If the subject continues to blow while exceeding the
minimum flow rate two more dashes will appear to the right of the head icon.

If the subject stops blowing before the sampling requirements have been met, one of the four
flow messages will appear and the device will re‐cycle to allow a second attempt to provide a
sample. After a very short wait the flashing head icon will reappear and the subject should be
directed to blow again. The device will allow up to three attempts to provide a breath sample
for each test sequence.

When all the sampling requirements are met there will be an audible click and the sample will
be  accepted  and  analyzed.  The  analysis  of  the  breath  sample  usually  takes  less  than  10
seconds to complete and there are three possible results:

Result displayed on screen
Digital Numerical Reading
WARN
FAiL

The test result will be displayed for about ten seconds and then the device will power  off
automatically. Show the reading to the subject. You can recall the test result using the menu
function, LAST (see Alco‐Sensor FST® Menu Functions on page 17).

4.2 Theory and Design of the Alco‐Sensor FST®
The Alco‐Sensor FST® contains a fuel cell sensor and an electrically operated sampling system. A
pressure sensor in the device monitors breath flow and volume to determine when to capture a
breath  for  analysis.  While  a  subject  is  blowing  and  when  deep  lung  breath  is  reached  the
sampling  system  is  activated.  A  small,  fixed  volume  of  deep  lung  breath  is  drawn  onto  the
surface of the fuel cell, any alcohol present in the sample is oxidized, generating a current. The
resulting  electric  current  is  translated  into  a  blood  alcohol  concentration  and  the  result  is
displayed on the Alco‐Sensor FST® in blood alcohol concentration units of milligrams of alcohol
in 100 milliliters of blood (mg%).
Display  ‐  The  display  and  the  back  light  turn  on  when  the  device  is  powered  ON.  Various
commands  and  symbols  appear  on  the  display  to  direct  the  operator  through  the  testing
procedure and alert the operator of improper testing conditions detected by the system.
Alco‐Sensor FST® Operator's Manual
BAC Level
0 to 59 mg%*
60 to 99 mg%
100 mg% or higher

13 of 30
Operator's Manual
PROTECTED A
2018‐12‐18
