Garden pavilion

Advertisement

NOTE: THIS UNIT IS HEAVY! For safety, DO NOT assemble this item alone. 4 people
are recommended for safe assembly.
WARNINGS:
 Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the assembly area of the gazebo.
 Some parts may contain sharp edges. Wear protective gloves.
 When assembling and using this product, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to equipment. Please read all
instructions before assembly and usage.
 For outdoor use only. Install on level ground.
 Check all bolts for tightness before and during usage.

Parts List

Post Screen
Post Screen
Post Screen
Post Screen
Beam Screen
Side Panel
Top Screen
Connect Bar
Note: It is recommended to use 4 people to complete the assembly steps.
It is recommended to use 2 ladders taller than 8.2 ft / 2.4 m when installing the top screens.
Garden Pavilion
ITEM#L-PG044PST
ASSEMBLY INSTRUCTIONS
A
2
B
2
C
2
D
2
E
2
F
2
G
6
H
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L-PG044PST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sunjoy L-PG044PST

  • Page 1 Garden Pavilion ITEM#L-PG044PST ASSEMBLY INSTRUCTIONS NOTE: THIS UNIT IS HEAVY! For safety, DO NOT assemble this item alone. 4 people are recommended for safe assembly. WARNINGS:  Keep all children and pets away from assembly area. Children and pets should be supervised when they are in the assembly area of the gazebo.
  • Page 2 Hardware Pack 1 M6X15 Bolt 8 PCS TBZ00106015HQ M6 Washer 8 PCS TBZ10406HQ M6X65 Bolt 20 PCS TBZ00108040HQ M6 Nut 20 PCS TBZ20108HQ M6 Washer 40PCS TBZ10408HQ M6 Wrench 2 PC Fig.1: Unfold the Side Panel F and keep it flat by the Connecting Bar H, the Bolt AA and the Washer BB. See Fig.1A Fig.1B: Place the unfold Side Panel F on a flat surface, attach it to the Post Screen C and the Post Screen D at the two ends of the Side Panel F with the Bolt CC and the Washer GG.
  • Page 3 Hardware Pack 2 M6X15 Bolt 4 PCS TBZ00106015HQ M6 Washer 4 PCS TBZ10406HQ M6X65 Bolt 8PCS TBZ00108040HQ M6 Nut 8 PCS TBZ20108HQ M6 Washer 16PCS TBZ10408HQ Fig.4: Unfold the Beam Screen E and keep it flat by the Bolt AA and Washer BB. See Fig.4 Fig.5: Attach the Beam Screen E to Post Screen A and Post Screen B with Bolt CC, the Nut DD and Washer GG.
  • Page 4 Important: Please do not return this product to the store. For technical assistance on assembly or replacement parts, please call Sunjoy Industries at 1(866) 578-6569 from 8:30 AM to 5:30 PM EST Monday to Friday or fax the replacement part form which put into the package to (740)-283-3549 or Email customer.care@sunjoydirect.com for assistance.
