- Page 1 MOVING HEAD USER MANUAL PT330W-R KEEP THIS MANUAL FOR FUTURE NEEDS...
-
Page 2: Table Of Contents
Thank you for purchasing a TERBLY product. You have acquired a powerful and versatile fixture. We are confident that you will be satisfied with our excellent products and service. For your own safety, please read this user manual carefully before installing and operating the device. -
Page 3: Safety Instructions
Make sure that the available voltage is not higher than that which is stated at the end of this manual. Make sure the power cord is never crushed or damaged by sharp edges.If this should be PT330W-R User Manual XM1147-V1.0-NR... - Page 4 If this device is operated in any way different to the ones described in this manual the product may suffer damage and the warranty becomes void.Furthermore any other operation may lead to short-circuits burns electric shocks etc. PT330W-R User Manual XM1147-V1.0-NR...
-
Page 5: Features
Reset DMX address remote lamp control reset can all be done by the DMX controller Running time of fixture on display for reference OTHER SPEC Can be changed 180° reverse to fit for different installation position. PT330W-R User Manual XM1147-V1.0-NR... - Page 6 WEIGHT Net weight: 21 kg PHOTOMETRIC DATA DMX CHANNEL CHART PT330W-R User Manual XM1147-V1.0-NR...
-
Page 7: Fixture Overview
9 Mode/Esc-button 10 Up-button 11 Handle 12 Lamp bracketrear metal panel 13 3-Pin DMX in 14 3-Pin DMX out 15 5-Pin DMX in 16 5-Pin DMX out 17 Power supply Fuse 19 Antenna – Wireless DMX PT330W-R User Manual XM1147-V1.0-NR... -
Page 8: Dimensional Drawings
4. DIMENSIONAL DRAWINGS PT330W-R User Manual XM1147-V1.0-NR... -
Page 9: Installation Instructions
Do not install lamps with a higher wattage.They generate higher temperatures than which the device was designed for. For the installation you need one MSD Platinum 16 R 330W PT330W-R User Manual XM1147-V1.0-NR... - Page 10 Please remember the lamp is not a hot-restrike lamp you must wait for approximately 10 minutes after having turned off the lamp before you can turn it back on again. CAUTION! DO NOT OPERATE THIS DEVICE WITH OPEN COVER PT330W-R User Manual XM1147-V1.0-NR...
- Page 11 Overhead mounting requires extensive experience including amongst others calculating working load limits installation material being used and periodic safety inspection of all installation material and the device.If you lack these qualifications do not attempt the installation yourself.Improper installation can result in bodily injury. PT330W-R User Manual XM1147-V1.0-NR...
- Page 12 Pull the safety cable through the holes on the bottom of the base and over the trussing system or another suitable rigging point. Insert the end into the carabiner and tighten the safety screw. Important This step is very important to ensure safe rigging of the fixture. PT330W-R User Manual XM1147-V1.0-NR...
- Page 13 PT330W-R User Manual XM1147-V1.0-NR...
-
Page 14: Dmx-512 Control Connection
DMX terminator is an XLR plug with a 120 resistor connected between pins 2 and 3 which is then plugged into the output (female) XLR socket of the last fixture in the chain.Please see illustrations below. PT330W-R User Manual XM1147-V1.0-NR... -
Page 15: Device Dmx Start Address Selection
In the case of the PT330W-R in 19 channel mode you should set the starting address of the first unit to 1 the second unit to 20 (19 + 1) the third unit to 39 (19+ 20) and so on. - Page 16 2. Do not connect the fixture which is under the communication of wireless system to the DMX controller otherwise it will cause interference from the DMX controller. PT330W-R User Manual XM1147-V1.0-NR...
-
Page 17: Display
ON/OFF Movement Feedback Movement Speed Speed 1~ 4 Movement Mode Select Mic Sensitivity 0~99% Sensitivity of Mic. Hibernation OFF 01M~99M 15M Stand by Mode Password Password=XXX Service Password“=050” Service Setting RDM PID XXXXXX RDM PID Code PT330W-R User Manual XM1147-V1.0-NR... - Page 18 2. Tap the <Up/Down> button until“Set DMX Address”is displayed. 3. Press ENTER the display will show“Set DMX Address”. 4. Tap the <Up/Down> button the display will show“A001~AXXX”. 5. Press ENTER to confirm or press <MODE/ESC> to return to the main menu. PT330W-R User Manual XM1147-V1.0-NR...
- Page 19 With this function you can display the temporary running time of the device from the last “XXXX”stands for the number of hours.The power on.The display shows“XXXX counter is reset after turning the device off. 1. Tap <MODE/ESC> button access the main menu Tap the <Up/Down> button until PT330W-R User Manual XM1147-V1.0-NR...
- Page 20 4 The display will show“XXXX” (Hours). 5 Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu. Lamp off time With this function you can display the temporary running time of the lamp from the last PT330W-R User Manual XM1147-V1.0-NR...
- Page 21 2 Press <Up/Down> the display will show“Lamp Time Password”. 3 Press< ENTER> the display will show“Lamp Time Password the time password is 038. 4 Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu. Clear Lamp Time PT330W-R User Manual XM1147-V1.0-NR...
- Page 22 Lamp is turned to ON but the lamp is not full dimming up. ·When the temperature unit after the temperature value come to capital letter “ C” or “ F it menu Lamp is turned to ON and the lamp is full intensity. PT330W-R User Manual XM1147-V1.0-NR...
- Page 23 Tap the <Up/Down>button until the display will show“Lamp Off Via DMX”. Press ENTER the display will show“Lamp Off Via DMX”. 2. Press <Up/Down> the display will show“OFF”or“ON”. 3. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu. PT330W-R User Manual XM1147-V1.0-NR...
- Page 24 1. Tap <MODE/ESC> button access the main menu Tap the <Up/Down> button until “Personality”is displayed.Press ENTER the display will show“Personality”.Tap the <Up/Down> button until the display will show “Status settings” .Press ENTER the display will show“Status settings”. PT330W-R User Manual XM1147-V1.0-NR...
- Page 25 “Personality”is displayed.Press ENTER the display will show“Personality”.Tap the <Up/Down> button until the display will show “Status settings” .Press ENTER the display will show“Status settings”. 2. Press <Up/Down> the display will show“Feedback”. 3. Press< ENTER> the display will show“Feedback”. PT330W-R User Manual XM1147-V1.0-NR...
- Page 26 5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu. 10.4.2. Service Setting Password The Password for this function is“050”. RDM PID With this function you can call up various submenus via RDM. This device is RDM ready.RDM stands for“remote device managemen”and makes remote PT330W-R User Manual XM1147-V1.0-NR...
- Page 27 “Personalit”is displayed.Press < ENTER> the display will show “Personality”.Tap the <Up/Down> button until the display will show“Display Setting”.Press ENTER the display will show“Display Setting”. 2 Press <Up/Down> the display will show“Key Lock”. 3 Press< ENTER> the display will show“Key Lock”. PT330W-R User Manual XM1147-V1.0-NR...
- Page 28 With this function you can reset the device via the Display.You can select the different reset functions from the display screen or a DMX console. 1 Tap <MODE/ESC> button access the main menu Tap the <Up/Down> button until PT330W-R User Manual XM1147-V1.0-NR...
- Page 29 “Users mode set”is displayed.Press <ENTER> the display will show“Users mode set”. 2 Press <Up/Down> the display will show “User Mode”. 3 Press< ENTER> the display will show“User Mode”. 4 The display show“Standard Mode Press <Up/Down> button then you can choose PT330W-R User Manual XM1147-V1.0-NR...
- Page 30 Program 2 Part 2 uses Program 4 Part 3 uses Program 6 Assume Program 2 includes scene of 10 11 12 13 Program 4 includes scene of 8 9 10 Program 6 includes scene of 12 13 14 15 Then it will run as below. Example PT330W-R User Manual XM1147-V1.0-NR...
-
Page 31: Dmx Protocol
0-255 Yellow Fine Color Wheel : 0-18 Open / white 19-37 Color 1 38-56 Color 2 57-75 Color 3 76-94 Color 4 95-113 Color 5 114-127 Color 6 128-189 Forwards rainbow effect from fast to slow PT330W-R User Manual XM1147-V1.0-NR... - Page 32 Forwards beam shaper rotation from fast to slow 190-193 No rotation 194-255 Backwards beam shaper rotation from slow to fast Rotating beam shaper indexing Fine 0-255 Fine indexing Zoom : 0-255 Continuous adjustment from far to near Zoom Fine: 0-255 Continuous adjustment Fine PT330W-R User Manual XM1147-V1.0-NR...
- Page 33 72-79 Macro9 80-87 Macro10 88-95 Macro11 96-103 Macro12 104-111 Macro13 112-119 Macro14 120-127 Macro15 128-135 Macro16 136-143 Macro17 144-151 Macro18 152-159 Macro19 160-167 Macro20 168-175 Macro21 176-183 Macro22 184-191 Macro23 192-199 Macro24 200-207 Macro25 208-215 Macro26 PT330W-R User Manual XM1147-V1.0-NR...
- Page 34 Internal program 6 (secne41~48 of EEPROM) 220-239 Internal program 7 (secne49~56 of EEPROM) 240-255 Music Control (secne of Program 1) Pan Fine 16bit 0-255 Fine control of Pan movement Tilt Fine 16bit 0-255 Fine control of Tilt movement PT330W-R User Manual XM1147-V1.0-NR...
-
Page 35: Error Messages
(Optical Sensor or Magnetic Sensor fails) or the stepper motor is defective (or its driving IC on the main PCB).The Zoom - movement is not located in the default position after the reset. PT330W-R User Manual XM1147-V1.0-NR... -
Page 36: Cleaning And Maintenance
3) A detailed electrical check by an approved electrician every quarter to make sure that the circuit contacts are in good condition.This will prevent poor circuit contacts and the resultant overheating. PT330W-R User Manual XM1147-V1.0-NR... -
Page 37: Service
Please refer to the instructions under“Installation instructions”. Should you need any spare parts please order genuine parts from your local dealer. 14. SERVICE For all service needs please contact your local authorized dealer or Terbly directly. Our contact details are: Email: QA@terbly.com...
