Tally Dascom DM-210/220

4 Specifications

4.1 Data Sheet

Print
Parameter
Cartridge
Ribbon
Copies
Paper Feed
Memory
Fonts
Detect
Function
Key and
LED Indicator
Power Supply
Paper Handle
9 pin dot matrix (Pin ф0.30mm)
Print method
bidirectional logic-seeking
Print direction
max 160dpiH x 144dpiV
Resolution
Print speed 4.3lps(4.3 line / sec at 42 columns)
Paper feed
max 5.51ips (14cm/s)
speed
42cpl @ 16.7cpi (7x8 matrix)
Print width
Cashbox: DC 24V, 1A, 6 line RJ-11 connector
USB 2.0: Full Speed, standard type B Connector
Serial RS232C: 25-pin Sub-D (f) connector; supports DTR or
Interface XON/XOFF handshaking protocol; baud rate 4800~38400BPS; data
Format 1 initial bit + 8 data bit + 1 or 2 stop bits, no Parity.
Parallel CENTRONICS: 25-pin Sub-D (m) connector, 8-bit parallel;
supports BUSY/ACK handshaking protocol.
Yes
Power Sleep
NH37701 (Purple), Lifetime: 3000,000 characters (Compatible to
ERC-39)
NH37703 (Black), Lifetime: 1000,000 characters
1+1 (Thickness: 0.05~0.08mm/page; Total thickness: ≤0.16mm)
Friction feed
Max. 32Kbytes data buffer
RAM
GB18030_2000 16x16
Chinese
7x8 and 9x8 ASCII font
Alphanumeric
PC437/PC850/PC860/PC863/PC865/PC858
Code page
In the direction of paper feed:
Mark height 5mm; Mark width min 12mm;
Black Mark Mark reflectivity < 10%; Non-mark reflectivity > 75%;
Detection Mark to initial print position: 27mm; Mark to tear position 47mm;
Factory default: Mark detection on the right for receipt face; Can be
changed to left using mark control commands.
Feed key
Key
Green LED
Power indicator
Red LED
Paper indicator
Red LED
Error indicator
External power adapter
AC 100V-240V 50-60Hz
Input
DC 24V±5%, 2.1A, A-1009-3P interface
Output
Good quality normal white roll paper or carbonized roll paper
Paper type
76.2±0.5mm (3 inch)
Paper width
0.06～0.085mm for single paper
Paper thickness
Paper roll Max. OD ф83mm
diameter ID ф10+2/-0mm
Upward cover open and Easy paper loading
Paper load
DM-210: Manual tear;
Paper cut DM-220: Auto-cutter; support full cut and partial cut.
Full cut (Cuts the paper completely)
13
