- Page 1 Hart Scientific Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 TestEquipmentDepot.com 9133 Infrared Thermometer Calibrator User’s Guide Rev. 531701...
- Page 2 Rev. 531701...
-
Page 3: Table Of Contents
Table of Contents 1 Before You Start ..... . 1 Symbols Used ......1 Safety Information . - Page 4 7.4.1 Scan Control ......22 7.4.2 Scan Rate....... . 22 Set-point Resistance .
- Page 5 11.2.1 EMC Directive ......43 11.2.2 Low Voltage Directive (Safety) ..... 43...
- Page 6 Figures Figure 1 Temperature Gradient Between Probe and IR Target Surface at Ambient of 30°C ......10 Figure 2 Back Panel .
- Page 7 Tables Table 1 International Electrical Symbols ..... . 1 Table 2 Controller Communications Commands ....32 Table 2 Controller Communications Commands continued .
-
Page 8: Before You Start
Before You Start Before You Start Symbols Used Table 1 lists the International Electrical Symbols. Some or all of these sym- bols may be used on the instrument or in this manual. Table 1 International Electrical Symbols Symbol Description AC (Alternating Current) AC-DC Battery CE Complies with European Union Directives... -
Page 9: Safety Information
9133 User’s Guide Symbol Description Canadian Standards Association OVERVOLTAGE (Installation) CATEGORY II, Pollution Degree 2 per IEC1010-1 refers to the level of Impulse Withstand Voltage protection provided. Equipment of OVERVOLTAGE CATEGORY II is energy-con- suming equipment to be supplied from the fixed installation. Exam- ples include household, office, and laboratory appliances. -
Page 10: Cautions
Replace the fuse once. If the fuse blows a second time, it is likely caused by failure of a component part. If this occurs, contact an Autho- rized Fluke Hart Scientific Service Center (see Section 1.3). Always re- place the fuse with one of the same rating, voltage, and type. Never replace the fuse with one of a higher current rating. - Page 11 9133 User’s Guide • DO NOT change the values of the calibration constants from the factory set values. The correct setting of these parameters is important to the safety and proper operation of the calibrator. • DO use a ground fault interrupt device.
- Page 12 Before You Start...
-
Page 13: Introduction
The Fluke Hart Scientific 9133 Mid-Range Field IR Calibrator may be used as a portable instrument or bench top temperature calibrator for calibrating point IR thermometers. The 9133 is small enough to use in the field, and accurate enough to use in the lab. Calibrations may be done over a range of -30°C to150°C (-22°F to 302°F). -
Page 14: Specifications And Environment Conditions
Specifications and Environment Conditions Specifications and Environment Conditions Specifications Temperature –30°C to 150°C (-22°F to 302°F) † Range ‡ Accuracy ±0.4°C (±0.72°F) [using 1/8" PRT] Stability ±0.1°C (±0.18°F) Target Size 2.25" (57 mm) Target Emissivity 0.95 (±0.02 from 8 to 14μM) Resolution 0.1°... -
Page 15: Environmental Conditions
9133 User’s Guide 0.15 0.05 -0.05 -0.1 -0.15 -0.2 Reference Probe °C Figure 1 Temperature Gradient Between Probe and IR Target Surface at Ambient of 30°C Environmental Conditions Although the instrument has been designed for optimum durability and trouble-free operation, it must be handled with care. The instrument should not be operated in an excessively dusty or dirty environment. - Page 16 Specifications and Environment Conditions...
-
Page 17: Quick Start
Unpack the calibrator carefully and inspect it for any damage that may have occurred during shipment. If there is shipping damage, notify the carrier immediately. Verify that the following components are present: • 9133 calibrator • report of calibration • power cord •... -
Page 18: Setting The Temperature
9133 User’s Guide grammed temperature set-point. The front panel LED display indicates the actual instrument temperature. Setting the Temperature Section 8.2 explains in detail how to set the temperature set-point on the calibrator using the front panel keys. The procedure is summarized here. -
Page 19: Parts And Controls
Parts and Controls Parts and Controls Back Panel The back panel (Figure 2) consists of the power inlet, power switch, serial port, and fan. 115V - 3AT 250V 115 VAC 50/60 Hz 3A 230V - 1.6AT 250V 230 VAC 50/60 Hz 1.6A RS-232 Figure 2 Back Panel Power Inlet –... -
Page 20: Front Panel
9133 User’s Guide Front Panel The front panel (Figure 3) consists of the controller display, controller key-pad, and target assembly. 9133 INFRARED CALIBRATOR –35°C to 150°C Smoked Display Window DOWN DOWN EXIT EXIT Figure 3 Front Panel Controller Display – The digital display displays set and actual tempera- tures and various calibrator functions, settings, and constants. -
Page 21: General Operation
Press the “UP” or “DOWN” button to change units. Switching to 230 V Operation The 9133 is switchable from 115 VAC to 230 VAC 50/60 Hz. To change from 115 VAC to 230 VAC follow the steps below. Unplug the instrument. - Page 22 9133 User’s Guide target at a rate that will not allow airflow to affect the target. Note: If the gas contains any moisture, ice will form on the target.
-
Page 23: Controller Operation
Controller Operation Controller Operation This section discusses in detail how to operate the instrument temperature controller using the front control panel. By using the front panel key-switches and LED display, the user may monitor the target temperature, adjust the set-point temperature in degrees C or F, monitor the output power, adjust the controller proportional band, and program the operating parameters, program parameters, serial interface configuration, and the con- troller calibration parameters. -
Page 24: Figure 4 Controller Operation Flow Chart
9133 User’s Guide Display DOWN Temperature Displays Set-Point Resistance Select Setpoint Toggles °C / °F Adjust Setpoint Automatically returns to display EXIT Units °C/°F Secondary Functions EXIT Scan On/Off Menu EXIT (2 Seconds) Display Power Scan Rate (2 Seconds) Set Proportional Band Adj. -
Page 25: Set-Point Value
Controller Operation 100.0 C Well temperature in degrees Celsius Access set-point memory 1 100. Set-point memory 1, 100°C currently used To change the set-point memory to another preset value press the “UP” or “DOWN” button. 4 150 New set-point memory 4, 150°C Press the “SET”... -
Page 26: Scan
9133 User’s Guide Un= C Scale units currently selected Press the “UP” or “DOWN” button to change the units. Change units Un = F New units selected Press the “SET” button to accept the new selection and resume displaying the display temperature. -
Page 27: Set-Point Resistance
Controller Operation Press the “SET” button to accept the new scan rate and continue. Accept scan rate Set-point Resistance To display the Set-point Resistance, press the “SET” and “DOWN” buttons si- multaneously when the temperature is displayed. When the “SET” and “DOWN”... -
Page 28: Proportional Band
9133 User’s Guide 12.0P Heater power in percent To exit out of the secondary menu press and hold the “EXIT” button. To con- tinue on to the proportional band setting function, press the “SET” button. Proportional Band In a proportional controller such as this, the heater output power is propor- tional to the target temperature over a limited range of temperatures around the set-point. -
Page 29: Controller Configuration
Controller Operation Proportional band setting To change the proportional band setting press the “UP” or “DOWN” buttons. Increment display New proportional band setting To store the new setting press the “SET” button. Press the “EXIT” button to continue without storing the new value. Accept the new proportional band setting 7.10 Controller Configuration... -
Page 30: Serial Interface Parameters
9133 User’s Guide 7.12 Serial Interface Parameters The serial interface parameters menu contains parameters, which determine the operation of the serial interface. The parameters in the menu are – baud rate, sample period, duplex mode, and linefeed. The serial RS-232 interface... -
Page 31: Duplex Mode
Controller Operation Press the “SET” button to store the new setting as the sample period or press the “EXIT” button to skip to the next parameter without storing the new setting. 7.12.3 Duplex Mode The next parameter is the duplex mode. The duplex mode may be set to full duplex or half duplex. -
Page 32: Alpha
9133 User’s Guide be altered. The correct values are important to the accuracy and proper and safe operation of the instrument. Access to these parameters is available to the user so that in the event that the controller memory fails the user may restore these values to the factory settings. -
Page 33: Digital Communication Interface
Digital Communication Interface Digital Communication Interface The 9133 calibrator is capable of communicating with and being controlled by other equipment through the digital interface. With a digital interface the instrument may be connected to a computer or other equipment. This allows... -
Page 34: Baud Rate
9133 User’s Guide the “EXIT” button while pressing the “SET” button and release to enter the secondary menu. Press the “SET” button repeatedly until the display reads “ProbE”. This is the menu selection. Press the “UP” button repeatedly until the serial interface menu is indicated with “SErIAL”. Finally press the “SET”... -
Page 35: Serial Operation
Digital Communication Interface 8.1.3 Serial Operation Once the cable has been attached and the interface set up properly the con- troller immediately begins transmitting temperature readings at the pro- grammed rate. The set-point and other commands may be sent to the instrument via the serial interface to set the instrument and view or pro- gram the various parameters. - Page 36 9133 User’s Guide Table 2 Controller Communications Commands Command Command Returned Acceptable Command Description Format Example Returned Example Values Display Temperature Read current set-point s[etpoint] set: 999.9 {C or F} set: 100.00 C Set current set-point to n s[etpoint]=n s=200.0...
- Page 37 Set BETA calibration be[ta]=n be=0.342 –100.0 to parameter 100.0 Functions not on menu Read firmware version *ver[sion] *ver ver.9999,9.99 ver.9133,1.0 number Read structure of all h[elp] list of commands commands Read all operating list of parameters parameters Legend: [] Optional Command data...
-
Page 38: Calibration Procedure
Calibration Procedure Calibration Procedure Sometimes the user may want to calibrate the instrument to improve the temperature set-point accuracy. Calibration is done by adjusting the control- ler probe calibration constants R0, ALPHA, DELTA, and BETA so that the temperature of the calibrator as measured with a standard thermometer agrees more closely with the set-point. -
Page 39: Compute Delta
− DE CF - Measured temperature using the reference thermometer 1– 4 - Value of R from the 9133 display (Press SET and DOWN at the same 1– 4 time) Where and R are the measured temperature and resistance at –25°C and R are the measured temperature and resistance at 0°C... -
Page 40: Compute Beta
Calibration Procedure 9.2.3 Compute BETA ⎡ ⎤ − ⎣ ⎢ ⎦ ⎥ ⎡ ⎤ ⎣ ⎢ ⎦ ⎥ delta − − beta )( ) )( ) alpha x y alpha x y Where T and R are the measured temperature and resistance at –25.00°C and alpha, rzero, and delta are the new values of ALPHA, R0, and DELTA calculated above. -
Page 41: Maintenance
Before using any cleaning or decontamination method except those recommended by Fluke Hart Scientific, users should check with an Au- thorized Fluke Hart Scientific Service Center (see Section 1.3) to be sure that the proposed method does not damage the equipment. -
Page 42: Troubleshooting
If the problem cannot otherwise be solved, contact an Authorized Fluke Hart Scientific Service Center (see Section 1.3). Be sure to have the model number and serial number of your instrument available. - Page 43 9133 User’s Guide Problem Possible Causes and Solutions The display shows Controller problem. The error messages signify the following any of the following: problems with the controller. Err 1 - a RAM error err 1 , err 2 , err 3 , err 4 ,...
-
Page 44: Comments
11.2.2 Low Voltage Directive (Safety) In order to comply with the European Low Voltage Directive (73/23/EEC), Fluke Hart Scientific equipment has been designed to meet the IEC 1010-1 (EN 61010-1) and the IEC 1010-2-010 (EN 61010-2-010) standards.
