The XPROG-m™ programmer is designed to replace the earlier version of
XPROG™ programmer. XPROG-m™ programmer is fully upward-
compatible hardware with XPROG™ programmer and have many additional
features.
The XPROG-m™ supports in circuit and on board programming 68HC05,
68HC08, 68HC11, 68HC(S)12, TMS370, AVR, ATMEGA, PIC, I²C, µW,
SPI, EEPROM and FLASH memories.

1.1. Main Features

• Fully compatible with all software versions of
Device Programmer Desktop™
• Software update (ATMEGA) - directly from
Device Programmer Desktop™;
• Software version control mechanism;
• Self check for errors handling;
• High speed RS232 communication interface, fully compatible
with USB RS232 adapter;
• Fully upward-compatible XPROG™ connector;
• Multifunctional XPROG-m™ connector;
• 8 pin DIP socked for on board programming;
• Supports many PLCC, QFP, LQFP adapters for on board
programming;
• High speed hardware engine(PLD);
• Two PWM regulated and ADC controlled voltage regulators.

1.2. Technical Data

Power Supply
- universal power provider: 100/240 Vac – 47/63 Hz/ 15 Vdc – 300mA;
Dimensions
Width 90mm
Length 90mm
Height 18mm
XPROG-m
Users manual

1. INTRODUCTION

WWW.ESOBD2.COM
TMT
© 2005
P/C: 3-001-0001
5
