2.3.

MC68HC11 family

2.3.1. MC68HC11A8/E1/E9/E20(PLCC52)

Optional-must be Lo
GND
B0
B1
B2
B3
Optional-must be Lo
B4
B5
B6
B7
Vcc
VppR
B0
XPROG pin
Signal level -

2.3.2. MC68HC11A8/E1/E9/E20(QFP64)

Optional-must be Lo
GND
B0
B1
B2
B3
Optional-must be Lo
B4
B5
B6
B7
Vcc
VppR
XPROG pin B0
Signal level -
XPROG-m
Users manual
PLCC52
/RESET
RxD
B1 B2 B3 B4
- 0/1 0/1 0
QFP64
/RESET
RxD
B1 B2 B3 B4
- 0/1 0/1 0
Mask sets:
Oscillator: 7, 8 pin
Packages: PLCC52
EEPROM: 0xB600 – 0xB7FF
B5 B6 B7
0/1 - - +5V 5%
Mask sets:
Oscillator: 31, 33 pin
Packages: QFP64
EEPROM: 0xB600 – 0xB7FF
B5 B6 B7
0/1 - - +5V 5%
© 2005
P/C: 3-001-0001
WWW.ESOBD2.COM
Vcc VppR
Vcc VppR
19
