2.2.5. MC68HC08AS60/AS60A(QFP64)

Optional-must be Lo
GND
B0
B1
B2
B3
Optional-must be Lo
B4
B5
Optional-must be Hi
B6
B7
Vcc
+9V
VppR
XPROG pin B0
Signal level
2.2.6. MC68HC08AZ60A(QFP64)
Optional-must be Lo
GND
B0
B1
B2
B3
Optional-must be Lo
B4
B5
Optional-must be Hi
B6
B7
Vcc
+9V
VppR
XPROG pin B0
Signal level
XPROG-m
Users manual
/IRQ
/RST
B1 B2 B3
- - - 0/1
/IRQ
/RST
B1 B2 B3
- - - 0/1
QFP64
B4 B5 B6 B7
0 0/1 1
QFP64
B4 B5 B6 B7
0 0/1 1
WWW.ESOBD2.COM
Mask sets: 0H62A, 8H62A
Oscillator: 58, 59 pin
Packages: QFP64
EEPROM1: 0x0800 – 0x09FF
EEPROM2: 0x0600 – 0x07FF
Vcc VppR
- +5V 5% +9V 5%
Mask sets:
Oscillator: 58, 59 pin
Packages: QFP64
EEPROM1: 0x0800 – 0x09FF
EEPROM2: 0x0600 – 0x07FF
Vcc VppR
- +5V 5% +9V 5%
TMT
© 2005
P/C: 3-001-0001
