2.3.9. MC68HC11KA4(PLCC68)

Optional-must be Lo
GND
B0
B1
B2
B3
Optional-must be Lo
B4
B5
B6
B7
Vcc
VppR
B0
XPROG pin
Signal level -

2.3.10. MC68HC11KA4(QFP64)

Optional-must be Lo
GND
B0
B1
B2
B3
Optional-must be Lo
B4
B5
B6
B7
Vcc
VppR
B0
XPROG pin
Signal level -
XPROG-m
Users manual
PLCC68
B1 B2 B3 B4
- 0/1 0/1 0
TxD
Vss
Vdd
QFP64
B1 B2 B3 B4
- 0/1 0/1 0
Mask sets: 0E57S
Oscillator: 56, 57 pin
Packages: PLCC68
EEPROM: 0x0D80 – 0x0FFF
MODB
/RESET
B5 B6 B7
0/1 - - +5V 5%
Mask sets: 0E57S
Oscillator: 59, 60 pin
Packages: QFP64
EEPROM: 0x0D80 – 0x0FFF
B5 B6 B7
0/1 - - +5V 5%
