2.6.

TMS374 family

The TMS374 family supported 14 wires in-circuit programming. The
suitable in-circuit programming interface must be used (see Figure 5). For
detailed in-circuit programming connections refer to "TMS374 family in-
circuit programming users manual" (P/C: 3-001-0002).
In-circuit programming
connector
Figure 5. The XPROG-m™ with TMS374 in-circuit
programming adapter
XPROG-m
Users manual
TMS374 ICP adapter
P/C: 1-002-0008
