3.2. Applied directives

Opto Engineering srl, with registered office in Strada Circonvallazione Sud 15, 46100
Mantova (Mn), Italy, states that the products described in this manual are marked with
"CE" and comply therefore with the following applicable Directives and their
amendments: RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, contact
Opto Engineering srl which will provide the support for disposal.
4.

SPECIFICATIONS

4.1. Specifications table

Optical specifications
Part number Mag.
circle Ø
(x) (mm)
0,250 11
0,500 11
TCZR036S
1,000 11
2,000 11
0,125 11
0,250 11
TCZR072S
0,500 11
1,000 11
Notes
Working F/#: the real F/# of a lens when used as a macro. Lenses with smaller apertures can be supplied on request
1
Maximum slope of principal rays inside the lens: when converted to milliradians, it gives the maximum measurement error for any millimeter
2
of object displacement
At the borders of the field depth the image can be still used for measurement but, to get a very sharp image, only half of the nominal field
3
depth should be considered.
Indicates the availability of an integrated camera phase adjustment feature
4
Encoder specifications
Number of encoders
DC power supply
Maximum supply current
Type
Signal outputs
Interface
Number of magnetic poles
Poles pitch
Interpolation
Pulses per revolution
Motor to encoder ratio
1
Notes
1 encoder pulse = 2.56 motor µsteps (with a 256 microstepping control)
1
Motor specifications
V 1.1 - eng
WD wF/# Telec. Distortion
(mm) (deg) (%)
1 2
< 0.05
< 0.04
74,0 16 < 0.05
< 0.04
< 0.08
< 0.1
< 0.08
157,8 16 < 0.05
< 0.05
< 0.07
1
(V) 5
(mA) 80
Magnetic rotary, incremental with reference
A, B, Z (index)
RS422
120
(mm) 2
500
60000
2.56
Mechanical specifications
Field CTF @70 Phase
Mount
depth lp/mm
(mm) (%)
3
13,2 > 40
3,3 > 35
C
0,8 > 40
0,2 > 35
53,0 > 35
13,2 > 40
C
3,3 > 40
0,8 > 35
Max Max
Length
adj. height width
(mm) (mm) (mm)
4
Yes 212,0 144 103
Yes 279,7 144 103
Mass
(g)
2500
2850
4
