opto engineering AOL0223B Instruction Manual

Adaptive lens for fast focusing
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AO series
Adaptive lens for fast focusing
v 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AOL0223B and is the answer not in the manual?

Questions and answers

Related Manuals for opto engineering AOL0223B

Summary of Contents for opto engineering AOL0223B

  • Page 1 AO series Adaptive lens for fast focusing v 1.1...

  • Page 2: Table Of Contents

    AO SERIES | INSTRUCTIONS MANUAL Index 1. General information ......................4 1.1 Installation, use and maintenance manual ..............4 1.2 Identification data of the product ..................4 1.3 Content of delivery ......................5 1.4 Overview of the product ....................5 2. Characteristics and description ..................6 2.1 Working principle ......................6 2.2 Technical specifications ....................7 2.3 Connections ........................9 2.3.1 Layout of connectors ....................9 2.3.2 Power supply ......................
  • Page 3 AO SERIES | INSTRUCTIONS MANUAL 4.2 Dll controls ........................24 4.2.1 Adaptive Lens DLL ....................24 4.2.1.1 Basic Data Structure ................24 4.2.1.2 Functions ....................24 4.2.2 AutoFocus DLL ....................28 4.2.2.1 Basic Data Structure ................28 4.2.2.2 Functions ....................28 4.3 TCP Communication .....................

  • Page 4: General Information

    AO SERIES | INSTRUCTIONS MANUAL 1. General information 1.1 Installation, use and maintenance manual Opto Engineering s.r.l., with its registered office in strada circonvallazione sud 15, 46100 Mantova (Mn) - Italy, hereinafter the manufacturer, provides all the necessary information in this installation, use and maintenance manual in a clear and simple way to install, use and service product AOL0223A and AOL0223B. The recipients of this manual are all those who have the knowledge, experience and capability of understanding the standards, prescriptions and safety measures indicated in this manual. Such people will be later identified as qualified personnel who are authorized to transport, install, use and service the products described in this manual. This material can only be used by the customer whom this manual has been delivered to in order to install, use and service the product.

  • Page 5: Content Of Delivery

    AO SERIES | INSTRUCTIONS MANUAL 1.3 Content of delivery The content of the delivery consists of: Adaptive focusing lens, positive or negative depending on the purchased P/N ➝ Adapter ring to mount the AO module on a lens with M30.5x0.5 filter thread ➝ 1.4 Overview of the product The fundamental parts of the product are listed below. Number Description Focusing lens Protective window Adapter ring 12-pin Hirose RJ45 Protective cover Clamping holes...

  • Page 6: Characteristics And Description

    AO SERIES | INSTRUCTIONS MANUAL 2. Characteristics and description 2.1 Working principle The AO series is a focusing module which can be mounted in front of a fixed focal length lens to rapidly change focus. The AO series allows the user to refocus the lens faster than moving the lens mechanically with traditional motorized solutions. The built-in driver has been specifically developed to accurately control the piezoelectric elements. A demo user interface with basic control functions is available via a web browser interface. The lens can also be fully controlled with a dedicated .dll library, downloadable from the Opto Engineering® website. The library includes an autofocus algorithm and a calibration tool to help users integrate the AO module into their product or application. There are two versions of the adaptive lens. Version A has positive optical power and version B has negative optical power. The positive lens can change the best focus plane from far to close while the focusing power moves from zero to the maximum power. The negative lens can change the best focus plane from close to far while the focusing power moves from zero to the maximum power.

  • Page 7: Technical Specifications

    AO SERIES | INSTRUCTIONS MANUAL 2.2 Technical specifications The technical specifications are indicated below. Part number AOL0223A Optical specifications Power (min) Power (max) Clear aperture (mm) Scan rate (Hz) Transmittance >90 Electrical specifications DC voltage Power consumption max Operating temperature 10 to 40 Storage temperature 0 to 50 Enviromental Humidity 10-85% non condensing...
  • Page 8 AO SERIES | INSTRUCTIONS MANUAL Part number AOL0223B Optical specifications Power (min) Power (max) Clear aperture (mm) Scan rate (Hz) Transmittance >90 Electrical specifications DC voltage Power consumption max Operating temperature 10 to 40 Storage temperature 0 to 50 Enviromental Humidity 10-85% non condensing...

  • Page 9: Connections

    AO SERIES | INSTRUCTIONS MANUAL 2.3 Connections 2.3.1 Layout of connectors RJ45 Connector Hirose 12-PIN Connector [ P.N.: HR10G-10R-12PB(71) ] Figure 1: view of the AOL0223X connections. Pinout for the 12-pin Hirose connector Pin Reference Connector top view Figure 2: Top view of the Hirose 12-pin connector for reference pin detection.

  • Page 10: Power Supply

    AO SERIES | INSTRUCTIONS MANUAL Connector Pinout CBGPIO001 WIRE COLOR ** Signal Blue GND (-) 24V (+) Pink Grey A/D_IN_0 Yellow Green DIG_OUT - Brown COMMON (Dig_IN) White RS232_RX* Black RS232_TX* Light Blue DIG_OUT + Orange A/D_IN_1 Violet Shield (no color) Table 1: Hirose 12-pin connector pinout (top view of male connector present on the AOL0223X). * RS232_RX and RS232_TX refer to the internal electronics.

  • Page 11: Rs232

    AO SERIES | INSTRUCTIONS MANUAL The default configuration uses a STATIC and PREDEFINED IP Address, but it’s possible to change this kind of configuration. In particular, a new static IP Address can be set by the user either via Ethernet or the serial RS232 (please refer to Paragraph 13 and 15 for IP Address reconfiguration). 2.3.4 RS232 The serial communication is implemented inside the Hirose 12-pin connector by using 3 pins, listed in the following table: Function Pin on Hirose Connector Cable color of CBGPIO001 Connect to Ground Brown AOL_RS232_RX White User_RS232_TX AOL_RS232_TX Black User_RS232_RX The electrical specifications of the RS232 signals are listed in the following tables: Specification Unit Data IN (User_TX) Data OUT (User_RX) -13.2 13.2 Specification Value...
  • Page 12 AO SERIES | INSTRUCTIONS MANUAL following schemes can be chosen (Figure 5): Inverting OPTO-ISOLATED OUTPUT LOGIC DIGITAL INPUT OPTO-ISOLATED OUTPUT Non-Inverting LOGIC DIGITAL INPUT DEVICE OPTO-ISOLATED INPUT OPTO-ISOLATED OUTPUT Inverting OPTO-ISOLATED OUTPUT Non-Inverting DEVICE OPTO-ISOLATED INPUT Figure 5: Two possible wiring configurations for the optoisolated output. The first two configurations refers to non opto-isolated digital inputs, the other two to opto-isolated digital inputs.

  • Page 13: Analog Control

    AO SERIES | INSTRUCTIONS MANUAL 2.3.6 Analog control AOL0223X includes two general purpose inputs which can be configured either as analog or digital. These are NOT optoisolated ports. The electrical scheme of these GPI is shown in Figure 6: 3.3V INPUT 1 20kohm 3.16kohm Electrical Specifications for A/D input ports Unit Input Voltage Input Dynamic Range (Discretization Levels) 3.3V (Voltage discretization) INPUT 2 20kohm 3.16kohm Figure 6: Electrical scheme of the two general purpose input ports. The input voltage divider is dimensioned to work with a 0-24V dynamic range for the input signal.

  • Page 14: Digital Control

    AO SERIES | INSTRUCTIONS MANUAL One possible application can be the following (Figure 7): an analog signal ranging from 0 to 24V can be fed to the “A/D_IN_0” pin, in a discrete ramp signal (Figure 8), as an example. For each input voltage level, a proportional output signal can be generated: once the output voltage reaches a steady-state value, the “DIG_OUT” pin can be used for triggering the image acquisition. After the end of the acquisition, the camera can communicate with the analog signal generator, thereby moving on to the next voltage level of the staircase signal. After having covered the entire input dynamic (0 – 24V), a set of different images has been acquired by the camera and is available to be processed in order to find the best focus. Considering the 12-bit resolution ADC, better precision can be achieved by increasing the number of input voltage levels. [V] IN ANALOG t [ms] Figure 8: Discrete ramp signal. 2.3.7 Digital control Pin 4 (A/D_IN_0) and Pin 11 (A/D_IN_1) can also be used as a digital input (0:LOW – 1:HIGH). In this case, an input signal whose value ranges between 0V and 8V is considered a LOW level digital signal (logic 0), whereas an input signal whose value ranges between 16V and 24V is considered a HIGH level digital signal (logic 1). Example AOL0223X 3.3V...

  • Page 15: Wiring Diagrams

    AO SERIES | INSTRUCTIONS MANUAL In this example, the two A/D input ports are directly linked to two different camera outputs. The first signal is “MOVE/STOP”, which is LOW when the best focus position has already been set, and HIGH when a new focus position must be reached. The other signal is “DIRECTION”: the AOL0223X only takes care of this signal if “MOVE/ STOP” is high. If DIRECTION is LOW, the output voltage applied to the piezoelectric actuator decreases, and when DIRECTION is HIGH, the output voltage increases. A suitable triggering, control and synchronization system is required between AOL0223X and the camera to implement this kind of control correctly. 2.3.8 Wiring diagrams This function code is used to write a block of contiguous registers in the controller register file. The master specifies the starting register address, the number of registers and the actual data to be written. Registers are addressed starting at zero. The register data in the request message are packed as two bytes per register. For each register, the first byte contains the high order bits and the second contains the low order bits. The normal response returns the function code, starting address, and quantity of registers written. Ethernet Port POWER SUPPLY 24 V AOL0223X is connected to the power supply and to the PC. Example 1: The connection to the PC via the ethernet cable is necessary for the electronic control of the Adaptive Lens. The default settings for the Ethernet connection are illustrated in Paragraph 11.3.
  • Page 16 AO SERIES | INSTRUCTIONS MANUAL POWER SUPPLY 24 V CAMERA Trigger IN Trigger OUT RS232 RX RS232 TX RS232 COM CAMERA CAMERA POWER SUPPLY AOL0223X is connected to the power supply and to the camera. Example 2: Commands are sent through RS232 signals. The output signal of the AOL0223X is used to let the camera know that the system is ready for the acquisition. Remember that this signal is OPTOISOLATED, therefore, for example, the “DIG_OUT +” can be connected to the camera power supply (or directly to the 24V if the camera is 24V tolerant) and “DIG_OUT -” to the TRIGGER IN of the camera. Ethernet Port CAMERA Trigger IN MOVE/STOP DIRECTION POWER SUPPLY 24 V CAMERA CAMERA POWER SUPPLY AOL0223X is connected to the power supply, to the camera and to the PC.

  • Page 17: Storage And Use

    AO SERIES | INSTRUCTIONS MANUAL Ethernet Port CAMERA Trigger IN MOVE/STOP POWER SUPPLY 24 V CAMERA CAMERA POWER SUPPLY AOL0223X is connected to the power supply, to the camera and to the PC. Example 4: The communication is based on TCP/IP protocol through Ethernet to the PC. In this case an analog control (described in Paragraph 11.6) is implemented to find the best focus: the analog signal coming from the camera or from an external source is fed to the input of the AOL0223X. The output signal (OPTOISOLATED) is used to trigger the image acquisition. Please refer to the previous example for configuring the optoisolated output signal. 3. Storage and use 3.1 Storage conditions 3.1.1 Temperature Storage environment between 0° and 50° C. Avoid thermal shock by not exposing the product to sudden changes in temperature. 3.1.2 Humidity Store the product in a dry place: storage environment with relative humidity (RH) less than 85% (no condensation).

  • Page 18: Humidity

    AO SERIES | INSTRUCTIONS MANUAL 3.2.2 Humidity Operating environment with relative humidity (RH) less than 85% (no condensation).. 3.2.3 Vibration and positioning The product is a high precision instrument. Avoid mechanical shock and exposure to vibrations: lenses are made of fragile materials which can fracture. Always handle the product with care and use appropriate clamping mechanics to position it. Never use optical parts of the product as means of mechanical support. Do not place the product on an unstable stand, tripod, base or table and on uneven floors. If the lens were to fall, it could cause personal injury and may be damaged. If the lens is placed vertically, with the mechanical axis nearly perpendicular (+/-30°) to the floor, operators should never place their hands under the lens, to avoid injuries due to the mechanical or optical components possibly falling. The device has an IP rating of 20 and should be installed in a way for moisture and dirt not to enter it. An enclosure may also be required for other parts of the system, such as power supplies. Such an enclosure would provide both mechanical and environmental protection in industrial applications. 3.3 Clamping and power supply 3.3.1 Mechanical fixing After the product has been set in place, according to the field of view, it can be secured by using at least 2 of the 6 M3 clamping holes.

  • Page 19: How To Use The Product

    AO SERIES | INSTRUCTIONS MANUAL 4. How to use the product 4.1 Demo interface 4.1.1 Software access The AOL0223X can be controlled either via Ethernet or RS232. This paragraph describes the Ethernet control method, highlighting the Demo interface functions. If the AOL0223X is switched on for the first time, a preliminary configuration is required. In fact, the default IP Address of the AOL0223X (written in a non-volatile memory) is 192.168.1.200: the PC network properties must be changed to access the web-based application. In particular, the following parameters have to be set in the Network Control Panel of the PC (TCP/IPv4): IP Address: 192.168.1.X (X can be a value that is not used by other peripherals - ➝ AOL0223X included – ranging from 1 to 255. Value 200 isn’t a valid value since it is used for the AOL0223); Subnet mask: 255.255.255.0; ➝ Default Gateway: not defined. ➝ The IP Address can be changed at any moment using both the DEMO program and the serial communication protocol (see Paragraph 13.5 and 15.2, respectively). Please be aware that if the new user-defined IP address is accidentally lost or forgotten, there is no possibility to retrieve it using the DEMO interface. However, the IP Address value can be retrieved using RS232 commands (see Paragraph 15.2). After the preliminary network configuration, the web-based DEMO interface can be easily accessed by entering the IP address 192.168.1.200 in the browser (or the new IP address, if changed).
  • Page 20 AO SERIES | INSTRUCTIONS MANUAL Once the IP address is connected to, the following web page will be displayed:...

  • Page 21: Lens Control

    AO SERIES | INSTRUCTIONS MANUAL 4.1.2 Lens control The first step to access all the functions of the AOL0223X is to enable the onboard electronics: to do this, click on the ON/OFF button at the top of the page; if the lens is switched ON, the ON/OFF button will turn green; otherwise, a grey button (default state) indicates that the lens is OFF. Before disconnecting the power supply, always remember to turn off the adaptive lens by clicking the OFF button! This is the correct procedure to switch off the adaptive lens properly. The slider bar can be used to manually adjust the focusing of the lens. This slider directly drives the output voltage applied to the piezoelectric actuator: the dynamic range of the output voltage is 0-300V and the current value (in % value) is displayed in the text box next to the slider. Please note that the slider works as an “on-release” button: the voltage is applied to the piezoelectric actuator when the mouse button is released. Manual control is obviously disabled when the lens is OFF. 4.1.3 Automatic Test Loop...

  • Page 22: Ip Settings

    AO SERIES | INSTRUCTIONS MANUAL The DEMO application includes an automatic test loop procedure, in which there is the possibility to save different positions (max. 5) directly related to the planes that have to be focused. All the commands are described in the following table: Automatic test commands Upload the percent value shown in the slider in one of the five positions of the loop. The default load position is the first position which is not used. Set focus Consider that this command allows the value to be loaded in one of the positions but this value is NOT loaded to the onboard memory. Load the value present in the text box to the onboard memory. Write This command, however, does NOT start the automatic procedure. Reset Reset the value of the relative loop position. Load from memory Allow to load the last value saved in the non volatile memory. Time period of the loop (T ): every T the lens changes its focusing properties by LOOP LOOP switching through the 5 different positions (max). Loop [ms] – textbox Consider that T is effectively given to the onboard electronics only after the START LOOP command of the automatic test loop. Valid values are between 10 ms and 10 s. Increase/Decrease the time period of the loop (T LOOP +/- buttons allow ±100 ms precision regulation of T...

  • Page 23: Analog/Digital Input Signals

    AO SERIES | INSTRUCTIONS MANUAL 4.1.6 Analog/Digital input signals This section allows the analog and digital control of the adaptive lens through external signals. Display the Input State shows the current state of When the adaptive lens is disabled, the input signals (pin 4 and 11 of the Hirose connector). In particular: • Display the Input State: 0 if both the signals are in a LOW state; • Display the Input State: 1 if A/D_IN_0 pin is HIGH and A/D_IN_1 pin is LOW; • Display the Input State: 2 if A/D_IN_0 pin is LOW and A/D_IN_1 pin is HIGH; • Display the Input State: 3 if both the signals are in a HIGH state. When the adaptive lens in enabled (see section 13.2) the analog/digital control of the lens is allowed via an external signal. To do this, the Input Control Enable button must be enabled: when on, the button will turn green. Two different control modes are possible: • Driving the lens through an external analog signal (see section 11.6 for electrical specifications) when the Enable Analog Input Control button is clicked. • Driving the lens through two separate digital signals MOVE and DIR (see section 11.7 for electrical specifications) when the Enable Digital Input Control button is clicked.

  • Page 24: Dll Controls

    AO SERIES | INSTRUCTIONS MANUAL 4.2 Dll control 4.2.1 Adaptive Lens DLL 4.2.1.1 Basic Data Structure struct AdaptiveLensDev char * ip; char * description; • char * ip (required field) • char * description (optional field) 4.2.1.2 Functions DLL_EXTERN_C DLL_API int Enable_Control(struct AdaptiveLensDev device, int &status); Parameters: • device • state (output value – actual Adaptive lens state) The function enables the device. It returns an error code (see error code table) DLL_EXTERN_C DLL_API int Disable_Control(struct AdaptiveLensDev device, int &status);...
  • Page 25 AO SERIES | INSTRUCTIONS MANUAL DLL_EXTERN_C DLL_API int Get_Position(struct AdaptiveLensDev device, int& currentFocusValue, int memoryPos); Parameters: • device • currentFocusValue (output value – focus value saved in onboard memory) • memoryPos (input value – memory position range [1-5]) The function sends a request for the stored focus value. It returns an error code (see error code table) DLL_EXTERN_C DLL_API int Reset_Position(struct AdaptiveLensDev device, memoryPos); Parameters: • device • memoryPos (input value – memory position range [1-5]) The function clears the value of the relative loop position. The device will ignore positions with no focus values.
  • Page 26 AO SERIES | INSTRUCTIONS MANUAL DLL_EXTERN_C DLL_API int Get_TriggerWidth(struct AdaptiveLensDev device, int& currentTriggerWidth); Parameters: • device • currentTriggerWidth (output value – trigger signal time duration saved onboard) The function sends a request for the trigger signal time duration. It returns an error code (see error code table). DLL_EXTERN_C DLL_API int Set_DeviceIP (struct AdaptiveLensDev device, char* newIp); Parameters: • device • newIp (input value – trigger signal time duration saved onboard) The function sets a new IP. It returns an error code (see error code table). DLL_EXTERN_C DLL_API int Set_PosMemory(struct AdaptiveLensDev...
  • Page 27 AO SERIES | INSTRUCTIONS MANUAL Allowed values: Value Input Range Focus value (%) 0-100 Memory Position (#) Rest Time (ms) 10-10000 Trigger Width 1-1000 Memory Positions (EEPROM) Error list: Error Write Communication error Error Read Communication error Error Parsing Communication error Error Socket Communication error Error invalid ok...

  • Page 28: Autofocus Dll

    AO SERIES | INSTRUCTIONS MANUAL 4.2.2 AutoFocus DLL 4.2.2.1 Basic Data Structure struct oeImage int w=-1; h=-1; unsigned char* data; int type=-1; int channels=-1; • int w - width (required field) • int h - height (required field) • unsigned char* data - (required field) • int type - data type (required field) 8 bit unsigned 8 bit signed 16 bit unsigned 16 bit signed 32 bit integer 32 bit float • int channels - 1 (grayscale) or 3 (color) struct...
  • Page 29 AO SERIES | INSTRUCTIONS MANUAL DLL_EXTERN_C DLL_API calculateBestFocusFull(oeImage inputImages[ ], unsigned int size, int &index, float &value); Parameters: • inputImages – input parameter, array of oeRoi structures • size – input value, size of inputImages array • index – output value, index of best focused image • value – output value, merit function output Error list: Error Code Description Cause • Image size is not initialized (w and/or h <0) Image Size Error • w and/ or h > 65535 Image channel Error Channel value =! 1 and =!3 Errors in Roi Paramaters • x<0 not initialized • y<0 not initialized Roi Error • w<0 not initialized • h<0 not initialized • x+w> Image width • y+h> Image height...

  • Page 30: Tcp Communication

    AO SERIES | INSTRUCTIONS MANUAL 4.3 TCP Communication The adaptive lens functions can be integrated directly, without using the AOL0223X libraries (.dll). The parameters that have to set for starting the communication by TCP can be found in the the AOL0223X libraries (the .h and the example.cpp files are available on the Opto Engineering website). In the following table the commands list is shown: Allowed Response Command Description String (request) input values (return value) If valid: 1 Lens Enable Turn on the adaptive lens /cgi-bin/enable_ctr If invalid: -1 If valid: 0 Lens Disabl Turn off the adaptive len /cgi-bin/disable_ctr If invalid: -1 Actuate the piezoelectric FOCUS (%): f valid: FOCUS (%) with the specified Set Output Voltage /cgi-bin/set_output_voltage: FOCUS...

  • Page 31: Serial Comunication Protocol

    AO SERIES | INSTRUCTIONS MANUAL Allowed Response Command Description String (request) input values (return value) ADDRESS: - X.X.X.X If valid: ADDRESS Set the static IP Address Set IP Address /cgi-bin/set_static_IPaddress: ADDRESS (with X of the device If invalid: -1 between 0 and 255) POS: - Min: 0 Save in the non volatile Save focusing power - Max: 99 /cgi-bin/save_position_focus: f valid: FOCUS memory of the device percentage value in...

  • Page 32: Functions

    AO SERIES | INSTRUCTIONS MANUAL 4.4.2 Functions The commands for driving the adaptive lens through serial interface are illustrated in the following table: Serial Explanation TYPE Command Description Example String of example GET FIRMWARE Get the current FW DEVICE INFO VERSION Version Get the MAC Address DEVICE INFO GET MAC ADDRESS of the device Set the IP address equal Set the IP Address, to 192.168.1.1 3 + IP SET IP DEVICE INFO by writing it in the 3 192.168.1.1 (This IP address will be...
  • Page 33 AO SERIES | INSTRUCTIONS MANUAL Serial Example TYPE Command Description Example String explanation 30 + SET OUPUT Set the focusing power Set the output percent CONFIGURATION 30 70 Focus (%) FOCUS PERCENT of the adaptive lens focus equal to 70% GET FOCUS Get the focusing power CONFIGURATION POWER of the adaptive lens 32 + Load the percent focus Set the focusing power SET FOCUS CONFIGURATION position + value into the specified 32 2 75...

  • Page 34: Examples

    AO SERIES | INSTRUCTIONS MANUAL 4.4.3 Examples This Paragraph shows some examples of the lens configuration via RS232 communication protocol. The wiring connections are not taken into account in the following examples. The serial command strings are within quotes (“”) and the command follows. Example 1: Manual calibration of the adaptive lens • “10” : turn on the onboard electronics of the adaptive lens; • “31” : get the current focusing power of the lens. It will be equal to 0%. • “30 40”: set the focusing power equal to 40%. The optical properties of the lens will change and a new focal plane will be focused. If 40% is not enough, a higher value will be necessary; • “30 70”: set the focusing power equal to 70%. A new plane will be properly focused and, if the focusing is satisfactory, this value can be saved in one of the automatic loop positions; • “32 1 70”: set the focusing power of the first position of the automatic test loop equal to 70%. • “11”: turn off the onboard electronics of the adaptive lens. Example 2: automatic procedure • “10”: turn on the onboard electronics of the adaptive lens; • “32 1 70”: set the focusing power of the first position of the automatic test loop equal to 70%; • “32 2 60”: set the focusing power of the second position of the automatic test loop equal to 60%; • “32 3 20”: set the focusing power of the third position of the automatic test loop equal to 20%;...

  • Page 35: Ethernet Firmware Update

    AO SERIES | INSTRUCTIONS MANUAL 4.5 Ethernet firmware update The current version of the firmware is displayed in the web DEMO interface at the top of the page: If a new version of the firmware is available, this can be loaded onto the adaptive lens onboard electronics. Before starting the update procedure, the firewall settings must be changed: ports 9, 67, 68 and 69 have to be opened, both in input and in output. To do this, two files are required: - AOL Bootloader.exe - the binary file (.bin) containing the new firmware release...

  • Page 36: Maintenance And Cleaning

    AO SERIES | INSTRUCTIONS MANUAL 5. Maintenance and cleaning DANGER: Risk of electric shock. Always disconnect the power supply before cleaning or performing maintenance WARNING: Cleaning and maintenance must only be performed by specialised and authorised personnel 5. How to clean Before cleaning the surface, take time to carefully inspect it and determine the type and severity of the contaminants. The only approved method for cleaning the optical surface is blowing off the surface by means of a canister of inert dusting gas or a blower...

  • Page 37: Aolm27X05Ar, Aolm305X05Ar, Aolm375X05Ar And Aolcm

    AO SERIES | INSTRUCTIONS MANUAL 5.2.1 AOLM27X05AR, AOLM305X05AR, AOLM375X05AR and AOLCM A - Remove the three no-head clamping screws with a screwdriver...

  • Page 38: Aolcf

    AO SERIES | INSTRUCTIONS MANUAL B - Remove the adapter ring C - Replace it with a new one, then screw again the no-head screw 5.2.2 AOLCF A - Remove the protective cover...
  • Page 39 AO SERIES | INSTRUCTIONS MANUAL B - Remove the screws with a proper torx screwdriver C - Remove the protective window to clean or replace it with a new one D - Put the AOLCF adapter ring in the same position as the protective window...

  • Page 40: How To Replace The Protective Window

    AO SERIES | INSTRUCTIONS MANUAL E - Screw the adapter ring F - Replace the cover 5.3 How to replace the protective window If necessary, the protective window can be removed. If the surface is broken or scratched, the optical window can be replaced. Please contact Opto Engineering® or the local distributor to buy the spare part. The instructions below must be followed to remove the protective window. WARNING: Never touch active components inside the lens below the protective window or the adaper ring WARNING: Always replace components in a cleand and dust-free environment...
  • Page 41 AO SERIES | INSTRUCTIONS MANUAL A - Remove the protective cover B - Remove the screws with a proper torx screwdriver C - Remove the protective window to clean or replace it with a new one...

  • Page 42: Extraordinary Maintenance

    AO SERIES | INSTRUCTIONS MANUAL 5.4 Extraordinary maintenance If electronic or optical components must be replaced, contact Opto Engineering s.r.l. and ask for support. 5.5 Disposal The device must be disposed of according to local regulations at the end of its service life, taking care to separate the components according to the material. Contact a specialized company to dispose of special materials, such as electronics and piezoelectric rings. 6. Safety notes 6.1 General disclaimer Always use and store Opto Engineering® products in the prescribed conditions in order to ensure they function properly: failing to comply with the following conditions may shorten the product lifetime and/or result in malfunctioning, performance degradation or failure.
  • Page 43 AO SERIES | INSTRUCTIONS MANUAL This device must not be used in an application where its failure could cause a hazard to human health or damage to other equipment. Keep in mind that if the device is used in a manner not foreseen by the manufacturer, the protection provided by its circuits and by its enclosure may be impaired. This is a low voltage power supplied device. As such, the potential difference between any combination of applied signals must not exceed the supply voltage at any time. Higher voltages may cause a fault and can be dangerous to human health. This device has limited protection against transients caused by inductive loads. If necessary, use external protection devices like fast diodes or better still, specific transient protectors. Do not allow foreign objects to enter the unit or drop into holes, terminals and other openings or gaps. This may cause fire or electric shock, possibly resulting in serious injury. Disconnect the power cable before moving the product. Failure to comply with this precaution may damage the power cable, cause fire or electric shock, possibly resulting in serious injury. Do not scratch, cut, open or twist the power cables. It may cause malfunctioning, fire or electric shock, possibly resulting in serious injury. If the power cable is damaged or cracked, please contact our assistance service and do not use the product. Damaged cables may cause malfunctioning, fire or electric shock, possibly resulting in serious injury. Do not insert or remove the plug of the power cable with wet hands. It may cause electric shock, possibly resulting in serious injury. Do not use the product in the presence of inflammable gas. It may cause outbreaks and flames, possibly resulting in serious injury. Should you notice any abnormality such as a smell, smoke or overheating, turn off the power and disconnect the power cables. Continuing to use the product in these conditions may cause fire or electric shock, possibly resulting in serious injury. If you have dropped the product or damaged the product case, turn off the power and disconnect the power cables. Continuing to use the product in these conditions may cause fire or electric shock, possibly resulting in serious injury.

  • Page 44: Product Warranty

    AO SERIES | INSTRUCTIONS MANUAL 7. Product warranty 7.1 Warranty The device warranty is 12 months from the effective delivery date with reference to the device serial number. The warranty covers the replacement or repairs of the defective part (components, device or part of it) with the exclusion of dismantling and shipping costs. The replacement of one or more components does not renew the warranty period of the entire device. The manufacturer cannot be held liable for any compensation for whatever reason and the buyer renounces any claims for costs or damages to third parties due to any machine downtime. The electronics and parts subjected to normal use or deterioration due to atmospheric agents and the external environment are excluded from the warranty. Also, all failure caused by the lack of, insufficient or incorrect maintenance performed by unskilled or unauthorized personnel or due to unintended use or unauthorized replacements, alterations or repairs is excluded from the warranty. The general validity of the warranty depends on: Maintenance being performed correctly as described in the device manual; ➝ The intended use of the device as specified in this manual. ➝ 7.2 Applied directives Opto Engineering srl, with registered office in Strada Circonvallazione sud 15, 46100 Mantova (Mn), Italy, states that the products described in this manual conform to the following EU directives: 2014/30/EU (EMC) following which all the following regulations and/or technical ➝ specification have been applied: Electrical equipment for measurement, EN 61326-1:2013 control and laboratory use - EMC requirements Part 1: General requirements Industrial, scientific and medical (ISM) radio-frequency equipment...

  • Page 45: Accessories

    AO SERIES | INSTRUCTIONS MANUAL 8. Accessories NOTE: Accessories listed below must be acquired separately if needed 8.1 Adapter rings The following table lists the available rings as at the date of issue of the manual. More rings can be found on the website or by asking Opto Engineering s.r.l. directly. AOLM27X05AR Adapter ring to mount the AO module on a lens with M27x0.5 filter thread AOLM305X05AR Adapter ring to mount the AO module on a lens with M30.5x0.5 filter thread AOLM375X05AR Adapter ring to mount the AO module on a lens with M37.5x0.5 filter thread AOLCM Adapter ring to mount the AO module on a C-mount camera Optional window with female C-mount thread to mount the AO module between AOLCF a lens and a camera 8.2 Cables CBGPIO001 I/O cable, side 1 HIROSE 12 pin, side 2 cable end, 3 m CBETH003 Ethernet cable, CAT6, industrial level,high flexible cable with screw, 5 m...
  • Page 46 EUROPE UNITED STATES Opto Engineering Opto Engineering Opto Engineering Opto Engineering Europe Headquarters Germany Russia Circonvallazione Sud, 15 Marktplatz 3 official partner 11321 Richmond Ave 46100 Mantova, IT 82031 Grünwald ViTec Co., Ltd, Fontanka emb., 170, Suite M-105, Houston, TX 77082 phone: +39 0376 699111 phone: +49 (0)89 693 9671-0 Saint-Petersburg, 198035, RU phone: +1 832 2129391 eu@opto-engineering.com...
