Black Box LB320A Quick Start Manual

LB320A Quick Start Guide
Distance and data rate for the Ethernet Extender port:
Table 6-1. Distance and Data Rate.
Distance (m) Data Rate (Mbps)
300 100
400 80
600 60
800 40
1200 20
2600 1
This distance/data rate information is measured
according to a testing standard in the laboratory. The
actual installation will be affected by the quality of the
copper wire and the impact of noise disturbance. The
connection speed will be affected.
