Phottix Ares Instruction Manual page 2

Parts
Transmitter
1. Status LED
2. Channel Numbers
3. Channel Adjustment Buttons
4. Fire All Button
5. Test Button
6. Swivel Rotator
7. Locking Ring
8. Camera Hot Shoe Connection
9. Power Switch
10. Battery Cover
11. Battery Compartment
2
8
1
2
4
5
7
3
11
9
10
6
