ICP DAS USA PM-3133 Quick Start Manual

1.
Shipping Package
This shipping package contains the following items
1 x PM-3133 module
2.
PM-3133 introduction
ICP DAS offers PM-3133 family in a full range of Single-phase and Three-phase smart power meters for power
monitoring. The products offer a rich feature set combined with easy-to-integrate communications.
With its high accuracy (<0.5%, PF=1), the PM-3133 series products can be applied both on low voltage primary
side and/or medium/high voltage secondary side and enable the users to obtain in real time the reliable and
accurate energy consumption readings from the monitored equipments while in operation. These compact size
and cost effective Power Meters are equipped with revolutionary wired clip-on CT (various types support input
current up to 200A) and standard Modbus communication RS-485 protocol for easy deployment. It works with
input voltages ranging 10V ~ 500V, supporting a wide range of applications.
2.1. Caution & Warning
electricians and metering specialist. ICP DAS assumes no responsibility if your electrical installer does not follow
the appropriate national and local electrical codes.
ICP DAS assumes no liability for any damage resulting from the use of this product. ICP DAS reserves the right to
change this manual at any time without notice. The information furnished by ICP DAS is believed to be accurate
and reliable. However, no responsibility is assumed by ICP DAS for its use, not for any infringements of patents or
other rights of third parties resulting from its use.
2.2. Product Warranty & Customer Support
ICP DAS warrants all products free from defects in material and workmanship for a period of one year from the
date of shipping. During the warranty period, we will, at our position, either repair or replace any product that
proves to be defective. To report any defect, please contact ：+886-3- 597-3366 or service@icpdas.com.
2.2.1. Limitation of Warranty
This warranty does not apply to defects resulting from unauthorized modification, misuse, or use for reason other
than electrical power monitoring. The supplied meter is not a user-serviceable product.
3.
Installation
Please use the soft dry clothes to clean the instrument.
Please do not use any chemical or detergent or volatile solvents to clean the instrument, in order to avoid any
possibility of the cover damage.
ICP DAS Co., LTD
PM-3133 Quick Start
1 x Quick Start
The meter contains hazardous voltages, and should never be disassembled. Failing to follow
this practice will result in serious injury or death. Any work on or near energized meters,
meter sockets, or other metering equipment could induce a danger of electrical shock. It is
strongly recommended that all work should be performed only by qualified industrial
PM-3133 Quick Start V1.20
Screw Driver x 1 CD x 1 Cable ties x 3
Page 1
