MACHINE SPECIFICATIONS

MODEL
Length
Width
Height
Weight
Solution Tank Capacity
Recovery Tank Capacity
Voltage
Total Power Consumption
Vacuum Motor
Water Lift - Air Flow
Heater
Solution Pump
Cord Length
Sound Pressure Level*
*
Sound levels (ISO 11203) as recommended by the American Association of Cleaning Equipment Manufacturers *(AACEM) and OSHA.
MACHINE DIMENSIONS
25.25 inches
10 10
NOBLES EXPLORER H2
32.5 in/ 826 mm
25.25 in/ 641 mm
41.5 in/ 1054 mm
100 lbs/ 46 kg
15 Gallon/ 56.78 L
13.5 Gallon/ 51.1 L
120 AC/ 60HZ
26.5A Nominal
120V, .685HP/ .504Kw, 3-stage, 13.2A
137 in/ 3479 mm, 107cfm
120V, 14A, 1750 W, 140°F/60°C low temperature,
200°F/93°C max temperature
115V, 1.6A, 0.8gpm/ 3.03 l/min, 220 PSI/15.16 bar
2 - 12/3, 40ft/ 12 m
75 dBA
641 mm
32.5 inches
826 mm
Nobles Explorer H2 (01/2014)
