Simplicity 1694153 Illustrated Parts List page 5

Hitch Group
REF NO. PART NO.
1 1960462
2 1924361
3 1668662
4 1960355
5 1916950
6 1916965
7 1707526
8 1921210
9 1703744
10 1723067
11 1920415
12 1723044
13 1960033
14 1931348
15 1723065
16 1723064
17 1917372
18 1917356
19 8271015
20 1960236
21 1960223
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1694153 Turbo Clean Sweep Twin Catcher
TP 400-2616-00-AT-SMA
QTY.
4 CAPSCREW, Hex Head, 1/2-13 x 2-1/2
4 WASHER
4 SPACER
4 LOCKNUT, Hex, 1/2-13
6 NUT, Hex, 3/8-16
6 LOCKWASHER, 3/8
1 SUPPORT, Upright
6 CAPSCREW, Hex Head, 3/8-16 x 1
1 BRACKET, Lower Hitch
2 SUPPORT, Side Hitch
6 CAPSCREW, Hex Head, 3/8-16 x 1-1/4
2 PLATE, Side
2 CLIP, Hair Pin
4 CARRIAGE BOLT, 3/8-16 x 3/4
1 CLAMP, Hitch
1 CLAMP, Plate
2 NUT, Hex, 5/16-18
2 LOCKWASHER
2 PIN, Round Head, Drilled
2 SPACER
2 CARRIAGE BOLT, 5/16-18 x 1-1/4
DESCRIPTION
5
