Page 3
1917372 1715758 1723309 1722922 Footnotes: The above parts group applies to the following Mfg. Nos.: 1694146 Hitch, Sub Frame TP 400-2546-00-AT-SMA DESCRIPTION RETAINER, Pin COLLAR, Set SCREW, Set, Square Head, Cup Point, 5/16-18 x 1/2, GR 8 TUBE & PIN ASSEMBLY...
Page 4
Hardware Identification & Torque Specifications Common Hardware Types Hex Head Capscrew Carriage Bolt Standard Hardware Sizing When a washer or nut is identified as 1/2”, this is the Nominal size , meaning the inside diameter is 1/2 inch; if a second number is present it represent the threads per inch When bolt or capscrew is identified as 1/2 - 16 x 2”, this means the Nominal size , or body diameter is 1/2 inch;...
