ATTACHMENT
OPERATOR'S
MANUAL
Clean Sweep
Triple Catcher
Clean Sweep Twin Catcher
Mfg. No.
Description
1694918
Clean Sweep Triple Catcher
1732353
Rev. 00
Rev. Date 02/2006
TP 100-4265-00-AT-SMAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1694918 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Simplicity 1694918

Summary of Contents for Simplicity 1694918

  • Page 1 ATTACHMENT OPERATOR’S MANUAL Clean Sweep Triple Catcher Clean Sweep Twin Catcher Mfg. No. Description 1694918 Clean Sweep Triple Catcher 1732353 Rev. 00 Rev. Date 02/2006 TP 100-4265-00-AT-SMAN...

  • Page 3: Table Of Contents

    Safety Rules & Information General Warnings...2 Safety Decals ...2 Storing the Grass Catcher ...3 General Operating Information Before Operation ...3 Mowing with the Catcher ...3 Required Accessories...3 After Operation ...3 Storing the Grass Catcher ...3 Initial Installation Hitch Installation ...4 Baffle Installation Baffle Installation ...5 Component Installation...

  • Page 4: Safety Rules & Information

    Safety Rules & Information Read these safety rules and follow them closely. Failure to obey these rules could result in loss of control of unit, severe personal injury or death to you, or bystanders, or damage to property or equipment. The trian- in text signifies important cautions or warnings which must be followed.

  • Page 5: Storing The Grass Catcher

    Mowing with the Catcher Always operate with throttle at full speed when mowing. Grass should be cut often, and not too short. If grass is too long or lush it may be necessary to keep ground speed to a minimum or to cut only half the width of the mower to prevent clogging.

  • Page 6: Initial Installation

    Initial Installation WARNING Before beginning any service work turn off the PTO, set the parking brake, turn off the ignition, and disconnect the spark plug wire(s). Initial Installation HITCH INSTALLATION 1. Slide the 5/16-18 speed nut (A, Figure 1) onto rear frame support (E) through square hole (C) so that the threaded side (B) is on the inside of tractor.

  • Page 7: Baffle Installation

    Baffle Installation 1. Determine which baffle to use. See Figure 3 Chart. 2. Lift side discharge chute (H, Figure 3). 3. Insert baffle (F) through discharge opening and posi- tion baffle into place. 4. Tighten carriage bolts (A) and nuts (E) on baffle (F). 5.

  • Page 8: Component Installation

    Baffle Installation Figure 4. Install Mounting Plate A. Mounting Plate B. Locknuts, 5/16-18 C. Carriage Bolts, 5/16-18 x 5/8 Component Installation INSTALL MOUNTING PLATE 1. Install mounting plate (A, Figure 4) to mower deck as shown. Secure with 5/16-18 x 5/8 carriage bolts (C) and 5/16-18 locknuts (A).
  • Page 9 Figure 7. Install Latch & Hinge to Cover Assembly A. Cover Assembly B. Latch C. Locknuts, ESNA, #10-24 D. Screws, #10-24 x 5/8 E. Hinge F. Locknuts, 1/4-20 G. Screws, Slotted, 1/4-20 x 1/2 INSTALL LATCH AND HINGE TO COVER ASSEMBLY 1.

  • Page 10: Initial Hitch & Tube Installation

    Initial Hitch & Tube Installation Figure 10. Install Tubes and End Caps A. Cross Bar B. Tubes C. Capscrews, 5/16-18 x 2 D. Locknuts, Center Lock, 5/16-18 E. Square End Plugs F. Round End Plugs INSTALL TUBES AND END PLUGS 1.

  • Page 11: Tube Installation

    Figure 14. Install Lower Tube A. Lower Chute Rod B. Mounting Plate C. Rubber Strap D. Discharge Deflector E. Locknut LOWER TUBE INSTALLATION 1. Lift discharge deflector up (D, Figure 14). 2. Insert lower chute rod (A) into mounting plate (B). 3.

  • Page 12: Normal Removal & Installation Collector Installation

    Normal Removal & Installation Figure 17. Normal Installation & Removal Normal Removal & Installation Collector Installation Note: See previous pages for more detailed installation and operation instructions if necessary. 1. Mount the the channel assembly (A, Figure 17) into hitch (D). Secure with by inserting pin (C) into the right side of hitch (D) and turning pin (C) counter- clockwise to lock in place.

  • Page 13: Collector Removal

    Collector Removal WARNING OPERATION WITHOUT BAGGER For operation without bagger, the mower deflector MUST be properly installed in the down position and retained by the spring latch. 1. Unhook strap (N) from pin (M). Slide middle tube into upper tube (O) and remove middle tube (S). Remove upper tube (O) from cover (B).
  • Page 16 M A N U F A C T U R I N G , I N C . Simplicity Mfg. Inc.500 N Spring Street / PO Box 997 Port Washington, WI 53074-0997 www.SimplicityMfg.com Simplicity Mfg. Inc. - Snapper Products 535 Macon Street McDonough, GA 30253 www.Snapper.com © Copyright 2006 Simplicity Manufacturing, Inc.
