Doyon ARTISAN 1T series Owner's Manual

Hide thumbs Also See for ARTISAN 1T series:
Table of Contents

Advertisement

Quick Links

See also: User Manual
ÉQUIPEMENT DOYON INC.
1255, rue Principale
Linière, Qc, Canada G0M 1J0
Tel.: 1 (418) 685-3431
Canada: 1 (800) 463-1636
US: 1 (800) 463-4273
FAX: 1 (418) 685-3948
Internet:
http://www.doyon.qc.ca
e-mail:
doyon@doyon.qc.ca
ARTISAN OVEN
OWNER'S MANUAL
Product / Produit: ___________________________________
Serial number / Numéro de série: ______________________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARTISAN 1T series and is the answer not in the manual?

Questions and answers

Related Manuals for Doyon ARTISAN 1T series

Summary of Contents for Doyon ARTISAN 1T series

  • Page 1 ÉQUIPEMENT DOYON INC. 1255, rue Principale Linière, Qc, Canada G0M 1J0 Tel.: 1 (418) 685-3431 Canada: 1 (800) 463-1636 US: 1 (800) 463-4273 FAX: 1 (418) 685-3948 Internet: http://www.doyon.qc.ca e-mail: doyon@doyon.qc.ca ARTISAN OVEN OWNER’S MANUAL Product / Produit: ___________________________________ Serial number / Numéro de série: ______________________...

  • Page 2: Table Of Contents

    DOYON ARTISAN OVEN IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS TABLE OF CONTENTS TO GET THE BEST PERFORMANCE OF YOUR MACHINE, READ CAREFULLY THIS MANUAL. 1. SHIPPING........................3 2.RECEPTION OF THE MARCHANDISE ..............3 3. INSTALLATION ......................4 3.1. DISTANCES TO RESPECT ................... 4 3.2.

  • Page 3: Shipping

    ATTENTION DOYON is not responsible for damages to the property or the equipment caused by personnel who is not certified by known organisations. 1. SHIPPING For your safety, this equipment has been verified by qualified technicians and carefully crated before shipment.

  • Page 4: Installation

    3. INSTALLATION POWER FAILURE WARNING WHEN YOU HAVE A POWER FAILURE, SHUT OFF THE OVEN POWER SWITCH TO PROTECT THE ELECTRONIC COMPONENTS WHEN THE POWER COMES BACK. FOR YOUR SAFETY DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF THIS OR ANY APPLIANCE.

  • Page 5: In General

    3.2 IN GENERAL Take off the packaging material with care. Take off all the material used for packing and accessories. 3.3 TO THE ELCTRICIAN Electrical supply installation must be in accordance with the electrical rating on the nameplate. Utility connections shall be designed to be disconnected without the use of tools or shall be of sufficient length to permit the equipment to be moved for cleaning.

  • Page 6: Introduction

    4. INTRODUCTION The Artisan’s control panel is used to independently determine the heat of: the top of the oven, the sole (stone) and the front of the oven. The steam is regulated by using 2 timers: TIMER and STEAM TIMER. It also controls various maneuvers necessary for the operation of the oven such as the on-off oven light, the on-off exhaust and INSTANT POWER REDUCER, enabling the steam generator.

  • Page 7: Description Of The Control

    5. DESCRIPTION OF THE CONTROL PANEL...
  • Page 8 1) TOP TEMPERATURE Displays the temperature of the TOP. It is also used in the parameter settings mode. 2) CLOCK Displays the cooking timer. When the cooking timer is running, the display shows the minutes remaining to complete the cooking time and a flashing light spot indicates that it is counting time.
  • Page 9 10) STEAM INJECTION KEY When steam is enabled and the steam button is pressed briefly, steam is injected with a scheduled duration.While injecting, the pilot key will be on. If the pilot light is flashing, it means that the oven temperature is not high enough to permit steam generation.

  • Page 10: Control Operation

    6. CONTROL OPERATION 6.1 TEMPERATURE ADJUSTMENT Select the temperature for the TOP or SOLE by pressing the TOP SOLE button, the corresponding display and button will remain intermittent. Select the desired temperature with the buttons , and confirm by pressing the intermittent button.

  • Page 11: Warning Messages

    7. WARNING MESSAGES 7.1 OPENING MESSAGE When plugging the oven in, some information on the type of the oven and other technical parameters will appear during a few seconds. Those informations are not for the use of the user. 7.2 COLD VAPOR MESSAGE If there is a need for vapour, the button should be pressed until the pilot light is turned on.
  • Page 12 Faults can be: • Rupture or inversion of the thermal converter TOP. In the display TOP • Rupture or inversion of the thermal converter SOLE. In the display SOLE • Rupture or inversion of the thermal converter STEAM. In the display TOP •...

  • Page 13: First Time Heating The Oven

    8. FIRST TIME HEATING THE OVEN The first time you heat the oven is very important for the future good use of the oven. Therefore, in order to avoid any damage, it is necessary to follow the parameters indicated below. Select the temperature in all chambers at 50 After reaching the temperature, wait 15 minutes.

  • Page 14: Troubleshooting

    10. TROUBLESHOOTING BEFORE CALLING FOR SERVICE ANSWERS TO MOST FREQUENT QUESTIONS Always cut off the main power before replacing any parts. Be careful with the water and electric wire supply system when pulling the oven. Control parts Remove the side panel of the oven by screwing out the screws.

  • Page 15: Oven Maintenance And Cleaning

    11. OVEN MAINTENANCE AND CLEANING It is recommended to use a water filter and to clean or replace it regularly to avoid accumulation of minerals inside the unit. Step by step Recommendations We recommend and sell: Clean the inside of the oven and the proofer. Dirt Buster III.
  • Page 16 FOR MORE INFORMATION, PLEASE CONTACT OUR OFFICE: DOYON EQUIPMENT INC. 1255, rue Principale Linière, Qc, Canada G0M 1J0 Tel. : 1 (418) 685-3431 Canada : 1 (800) 463-1636 U.S. : 1 (800) 463-4273 FAX : 1 (418) 685-3948 Internet: http://www.doyon.qc.ca E-Mail : doyon@doyon.qc.ca...

  • Page 17: Component Parts

    COMPONENT PARTS...
  • Page 18 1T_TABLE ALARM TIMER ALARM TIMER ALARM TIMER 1T_TABLE...
  • Page 19 Front view Item Part Number Description Quantity MPA168 LOCKING CASTER (FRONT OF THE OVEN) & MPA167 NON LOCKING CASTER (BACK OF THE OVEN) PA0341C LEGS WITHOUT CASTERS (25") PA0342C LEGS WITHOUT CASTERS (16") PA0343C LEGS WITHOUT CASTERS (13") PA0344C LEGS WITHOUT CASTERS (1") PA009CN BLACK KNOB FOR STEAM DAMPER (CN CHAMBER) PA009CA...
  • Page 20 1T_TABLE 7 8 9 10 1 : ON 1 : ON 1 : ON 1 : ON 1 : ON 1 : ON 1 : ON 1 : ON 1T_TABLE...
  • Page 21 Side view Item Part Number Description Quantity MER001 ELEMENT BLOCK 208V – 240V (1T) MER001A ELEMENT BLOCK 480V (1T) MER011 LIGHT BULB TYPE MR16 & MER019 SOCKET FOR 20W LIGHT BULB MER068 TRANSFORMATOR 240V > 12V, 24V & TRANSFORMATOR 240 > 24 IF WATER SOLENOID VALVE IS 24 VAC TERMINAL BLOCK FOR BUZZER MEC042 &...
  • Page 22 1T_TABLE 1T_TABLE...
  • Page 23 Back view Item Part Number Description Quantity STEAM GENERATOR BOX ASSY & WATER INJECTOR MER059 ELEMENT 600W 230V FOR THE STEAM GENERATOR MER027A ELEMENT 600W 40V FOR STEAM MEC014A SOLENOID VALVE 24 VAC 50 Hz 27 VA MEC014B SOLENOID VALVE 12 VAC 50 Hz 27 VA 1T ARTISAN DECK OVEN (BACK VIEW)
  • Page 24 2T_TABLE ALARM TIMER ALARM TIMER ALARM TIMER 2T_TABLE...
  • Page 25 Front view Item Part Number Description Quantity MPA168 LOCKING CASTER (FRONT OF THE OVEN) & MPA167 NON LOCKING CASTER (BACKOF THE OVEN) PA034-1C LEGS WITHOUT CASTERS (25") PA034-2C LEGS WITHOUT CASTERS (16") PA034-3C LEGS WITHOUT CASTERS (13") PA034-4C LEGS WITHOUT CASTERS (1") PA009CN BLACK KNOB FOR STEAM DAMPER (CN CHAMBER) PA009CA...
  • Page 26 2T_TABLE 6 7 8 9 10 11 1 : ON 1 : ON 1 : ON 1 : ON 1 : ON 1 : ON 1 : ON 1 : ON 2T_TABLE...
  • Page 27 Side view Item Part Number Description Quantity MER002 ELEMENT BLOCK 208V – 240V (2T) MER002A ELEMENT BLOCK 480V (2T) MER002B MER011 LIGHT BULB TYPE MR16 & MER019 SOCKET FOR 20W LIGHT BULB MER068 TRANSFORMATOR 230V > 12V (IF WATER SOLENOID VALVE 12 VAC) ELT705 TRANSFORMATOR 120-240 V / 12-24 V 100 VA (IF WATER...
  • Page 28 2T_TABLE 2T_TABLE...
  • Page 29 Back view Item Part Number Description Quantity STEAM GENERATOR BOX (WATER INLET & DRAIN AT THE SAME END STEAM GENERATOR BOX (WATER INLET ON THE BACK SIDE MER027 ELEMENT 600W 230V FOR STEAM GENERATOR MER027A ELEMENT 600W 480V FOR STEAM GENERATOR MEC014A SOLENOID VALVE 24 VAC 50 Hz 27 VA MEC014B...
  • Page 30 3T_TABLE ALARM TIMER ALARM TIMER ALARM TIMER 3T_TABLE...
  • Page 31 Front view Item Part Number Description Quantity MPA168 LOCKING CASTER (FRONT OF THE OVEN) & MPA167 NON LOCKING CASTER (BACKOF THE OVEN) PA0341C LEGS WITHOUT CASTERS (25") PA0342C LEGS WITHOUT CASTERS (16") PA0343C LEGS WITHOUT CASTERS (13") PA0344C LEGS WITHOUT CASTERS (1") PA009CN BLACK KNOB FOR STEAM DAMPER (CN CHAMBER) PA009CA...
  • Page 32 3T_TABLE 9 10 11 12 13 1 : ON 1 : ON 1 : ON 1 : ON 1 : ON 1 : ON 1 : ON 1 : ON 3T_TABLE...
  • Page 33 Side view Item Part Number Description Quantity MER002 ELEMENT BLOCK 208V – 240V (2T) MER002A ELEMENT BLOCK 480V (2T) MER011 LIGHT BULB TYPE MR16 & MER019 SOCKET FOR 20W LIGHT BULB TRANSFORMATOR 120V > 12V, 24V TERMINAL BLOCK FOR BUZZER MEC042 &...
  • Page 34 3T_TABLE 3T_TABLE...
  • Page 35 Back view Item Part Number Description Quantity MER059 ELEMENT 600W 230V FOR STEAM GENERATOR MEC014A SOLENOID VALVE 24 VAC 50 Hz 27 VA MEC014B SOLENOID VALVE 12 VAC 50 Hz 27 VA 3T ARTISAN DECK OVEN (BACK VIEW)
  • Page 36 The purchaser is responsible for having the equipment properly installed, operated under normal conditions with proper supervision and to perform periodic preventive maintenance. If any parts are proven defective during the period of one year from date of purchase, Doyon Equipment Inc. hereby guarantees to replace, without charge, F.O.B. Linière, Quebec, Canada, such part or parts.

This manual is also suitable for:

Artisan 2t seriesArtisan 3t series
