Summary of Contents for Doyon JA12SL

Page 1 Operation / instruction for oven and proofer........
Page 2 120V/208V/3PH & 120V/240V/3PH (DELAY) ....JA12SL 120V/208V/1PH & 120V/240V/1PH ......
Page 3: Introduction
This Jet Air oven is manufactured with first quality material by experienced technicians. Proper installation and maintenance will guarantee a reliable service for years to come. A nameplate fixed to the front or right side of the oven specifies the model number, serial number, voltage and amperage.
Page 4: Construction
CONSTRUCTION You just bought the most advanced oven in the world, "DOYON" technology at its best. This oven is manufactured using the highest quality components and material. The oven gives a perfect uniform baking with its unique Jet Air convection system. The DOYON oven is designed with parts that are easy to find.
Page 5: Installation Warnings
Installation and service must be done by specialised technicians. Contact a certified electrician and plumber for set up. The oven must be connected to the utility and electrically grounded in conformity to the effective local regulations. If these are not established, the oven must be connected according to the Canadian Electrical Code (CSA-C22.1-XX) or National Electrical Code (NFPA 70-XX).
Page 6: Distances To Respect
DISTANCES TO RESPECT Back and sides of the oven: 1 inch. Top of the oven: a clearance of 12 inches to the ceiling must exist to permit adequate venting. Floor: 4 inches minimum. Sides of the oven: do not install other than easily removable equipment for service and maintenance (not closer than 1 inch).
Page 7: Installation
Connect the steam system (1/4 NPT) to the cold water distribution network. We highly recommend to use a water softener to eliminate minerals in the water. We suggest you to use CUNO # CFS6135 (Doyon part number PLF240). Do not adjust the needle valves, it has been done at the factory.
Page 8: Troubleshooting
5. Set the timer to the desired value and start it. (See "TIMER" adjustment on next page.) NOTE: The timer does not shut the oven off at the end of its cycle. It simply activates the buzzer. 6. Wait until the product is ready. Do not open the doors until the product is done.
Page 9: Instructions For Oven
Steam injection will only work when the ventilator of the oven is working. To inject steam in the oven, press and release the STEAM TIMER button. The light comes on inside the steam button during the steam injection. Steam injection has been factory preset. To have more steam, press steam button a second time, after the light is off.
Page 10: Operation Of The Proofer
OPERATION OF THE PROOFER 1. Switch "ON". 2. Set the thermostat control at 100 3. Set the humidity control at approximately : 3 for JAOP-3 & JAOP-6 4. If there is too much fog and water drips from the glass doors, adjust humidity control to a lower number.
Page 11: Troubleshooting
If the oven is baking too much on the sides, it is possible that the fan is not cycling properly. Verify if the motor turns 2.5 minutes in a direction, stops 30 seconds and starts for 2.5...
Page 12 If there is no heat in the proofer. If there is no humidity in the proofer. The oven must have been heating for at least half an hour before you use the steam system. If not, water will appear at the bottom of the oven.
Page 13: Oven Maintenance And Cleaning
• Once a year or as needed, clean the reservoir of the proofer (see parts description for localization). Step by step Clean the inside of the oven and the proofer with water and soap. Take out the grills (the grills of the oven could be cleaned with "Easy-Off").
Page 14: For More Information, Please Contact Our Office
FOR MORE INFORMATION, PLEASE CONTACT OUR OFFICE: DOYON EQUIPMENT INC. 1255, rue Principale Linière, Qc, Canada G0M 1J0 Tel. : 1 (418) 685-3431 Canada : 1 (800) 463-1636 U.S. : 1 (800) 463-4273 FAX : 1 (418) 685-3948 Internet: www.doyon.qc.ca E-Mail : doyon@doyon.qc.ca...
Page 15 AUTOMATIC STEAM OPTION INTERVALS TIMES SETTING (GREEN) INJECTION TIMES SETTING (RED) SCALE ADJUSTMENT By pushing the GREEN button, the button will light up and the automatic system injection will start. The injection will be done as per the pre-adjustment time on the automatic steam timer. The standard steam timer (white light) will light up during the steam injection.
Page 16 Digital display must light up, if not verify the breaker on the front panel. 3. Let the oven heat until the set temperature is reached, the LOAD1 red light on the watlow control will go off when the temperature is stabilized.
Page 17 The Watlow temperature control can record 12 different menus. It must be programmed before use. It will save its programs in case of power failure. Each menu includes 3 "STEPS" and each step includes : • temperature • time • "EVENT" To access the programming mode : •...
Page 18 CLOCK). The screen will show 00:00. Note: You should always use menu #1 for preheating because the controls starts automatically with this menu. Never use program #1 for a steam cycle because it will start automatically when the oven is Suggested values Suggested values WARNING turned on.
Page 19 EXAMPLE 2 (Cooking program with steam cycle) -For menu #2, we will program it so that we have a steam injection of 20 seconds, a cooking time of 20 minutes at 375°F followed by a 15 seconds buzzer. To access the programming mode: •...
Page 20 After fulfillment of this program: • The oven will continue to heat because there was a temperature included in step 3. If the temperature at that step would have been of 0°F, the oven would have stopped at the end of the program.
Page 21 SECTION DIMENSIONS...
Page 22: Jaop6Sl
JAOP6SL BAKING TIMER THERMOSTAT JAOP6SL 72 3/4 OVEN INTERIOR DIMENSIONS HEIGHT 26 1/4" WIDTH 26 3/4" DEPTH 19 1/2" PROOFER INTERIOR DIMENSIONS HEIGHT 26 1/4" WIDTH 27" DEPTH 29 1/4"...
Page 23 JAOP6SL 37 1/2 JAOP6SL...
Page 24 JAOP6SL ENTRÉE D’EAU Ø1/4 WATER INLET Ø1/4 PIPE ENTRÉE ÉLECTRIQUE ELECTRICAL INLET 61 5/8 39 1/8 JAOP6SL...
Page 25: Ja6Slsc
JA6SLSC WATLOW 5 AMPS 72 3/4 OVEN INTERIOR DIMENSIONS HEIGHT 26 1/4" WIDTH 26 3/4" 19 1/2" DEPTH JA6SLSC...
Page 26 JA6SLSC 37 1/2 JA6SLSC...
Page 27 JA6SLSC ENTRÉE D’EAU Ø1/4 WATER INLET Ø1/4 PIPE ENTRÉE ÉLECTRIQUE ELECTRICAL INLET 61 5/8 39 1/8 JA6SLSC...
Page 28: Ja6Sl
JA6SL JA6SL...
Page 29 JA6SL JA6SL...
Page 30 JA6SL JA6SL...
Page 31: Ja12Sl
JA12SL BAKING TIMER THERMOSTAT BAKING TIMER THERMOSTAT JA12SL 72 3/4 OVEN INTERIOR DIMENSIONS HEIGHT 26 1/4" WIDTH 26 3/4" 19 1/2" DEPTH...
Page 32 JA12SL 37 1/2 JA12SL...
Page 33 JA12SL ENTRÉE D’EAU Ø1/4 WATER INLET Ø1/4 PIPE ENTRÉE ÉLECTRIQUE ELECTRICAL INLET 61 5/8 39 1/8 JA12SL...
Page 34: Jaop12Sl
JAOP12SL JAP12SL...
Page 35 JAOP12SL 37 1/2 JAP12SL...
Page 36 JAOP12SL JAP12SL...
Page 37: Component Parts
SECTION COMPONENT PARTS...
Page 38 JAOP6SL BAKING TIMER THERMOSTAT JAOP6SL...
Page 39 LEFT DOOR FOR PROOFER 15" X 28 3/4"(JAOP-6-SL) QUE500 P1529ED RIGHT DOOR FOR PROOFER 15" X 28 3/4"(JAOP-6-SL) P1529FG LEFT DOOR FOR OVEN 15" X 28 3/4"(2 FOR JA-12-SL) QUE500 P1529FD RIGHT DOOR FOR OVEN 15" X 28 3/4"(2 FOR JA-12-SL) ELL850 RED ILLUMINATED BUTTON FOR ELL795(AUTO.
Page 40 JAOP6SL JAOP6SL...
Page 41 Item Part Number ELE165 ELE167 IMMERSION ELEMENT 240V 1500W(220V 50-60 Hz) ELE130 ELE132 ELM730 ELM570 ELS950 ELT503 ELT507 ELD050 ELT506 ELC615 ELC617 ELS880 QUF350 ELT712 ELT715 ELC630 ELC640 Model : JAOP6SL-E Description IMMERSION ELEMENT 120V 1500W COIL ELEMENT 120V 1500W COIL ELEMENT 240V 1500W(220V 50-60 Hz) PROOFER FAN BLOWER DOOR SWITCH...
Page 42 JAOP6SL JAOP6SL...
Page 43 Item Part Number ELP810 CONTROL PANEL 240V 1PH SINGLE ELP820 CONTROL PANEL 208V 3PH SINGLE (PANEL 220V 1PH 50Hz) (PANEL 220/380V 3PH 50Hz) ELM800M MOTOR .75HP 1PH 115/208-230V 60Hz/50Hz A.O. SMITH ELM820M MOTOR 3/4HP 3PH 208/230/460V 60Hz/50Hz A.O. SMITH PLF100 WATER FILTER ELS880 SOLENOID VALVE 110/120V 50/60Hz...
Page 44 JA6SLSC WATLOW 5 AMPS JA6SLSC...
Page 45 SWIVEL CASTER WITH BRAKE QUA200 DOOR MAGNET QUP320 DOOR HINGE QUP465 DOOR HANDLE STAINLESS TUBING P1529FG LEFT DOOR FOR OVEN 15" X 28 3/4" AND QUE500 DOOR GASKET ((10`) P1529FD RIGHT DOOR FOR OVEN 15" X 28 3/4" ELM760 MOTOR BLOWER ELT535...
Page 46 JA6SLSC JA6SLSC...
Page 47 Item Part Number ELM570 DOOR SWITCH ELS950 BUZZER 120V ELD050 INCANDESCENT LIGHT SOCKET & ELA275 BULB 60W 130V ELT506 HIGH LIMIT TEMPERATURE ELC800 SOLID STATE RELAY (S.S.R.) ELF960 LITTLE-FUSE HOLDER 30A 300V AND ELF855 LITTLE-FUSE 1A 250V GAT100 TRANSFORMER 120/25V 20VA. Model : JA6SC WATLOW Description View : SIDE...
Page 48 JA6SLSC JA6SLSC...
Page 49 Item Part Number ELP810 CONTROL PANEL 240V 1PH SINGLE ELP820 CONTROL PANEL 208V 3PH SINGLE ELM800M MOTOR .75HP 1PH 115/208-230V 60Hz/50Hz A.O. SMITH ELM820M MOTOR 3/4HP 3PH 208/230/460V 60Hz/50Hz A.O. SMITH PLF100 WATER FILTER ELS880 SOLENOID VALVE 110/120V 50/60Hz ELV590 NEEDLE VALVE Model : JA6SC WATLOW Description...
Page 50 SECTION CONTROL PANELS...
Page 51 240 VOLTS 1 PHASE SIMPLE−DELAY PAN240S...
Page 52 ELM720 OMRON CONTROL TIMER (11 PIN) H3CR(DELAY OPTION) AND ELM729 11 PIN BASE(DELAY OPTION) ELC630 CONTROL RELAY 12A COIL 120V(AUTO. STEAM OPTION) AND ELC640 CONTROL RELAY BASE(AUTO. STEAM OPTION) Model : PA240SP(JAOP6) Description View : INSIDE (See OVEN BACK) Quantity...
Page 53 208 VOLTS 3 PHASES SIMPLE−DELAY PAN208S...
Page 54 ELM720 OMRON CONTROL TIMER (11 PIN) H3CR(DELAY OPTION) AND ELM729 11 PIN BASE(DELAY OPTION) ELC630 CONTROL RELAY 12A COIL 120V(AUTO. STEAM OPTION) AND ELC640 CONTROL RELAY BASE(AUTO. STEAM OPTION) Model : PA208SP(JAOP6) Description View : INSIDE (See OVEN BACK) Quantity...
Page 55 220/380 VOLTS 3 PHASES SIMPLE−DELAY PAN380S...
Page 56 ELM720 OMRON CONTROL TIMER (11 PIN) H3CR(DELAY OPTION) AND ELM729 11 PIN BASE(DELAY OPTION) ELC630 CONTROL RELAY 12A COIL 120V(AUTO. STEAM OPTION) AND ELC640 CONTROL RELAY BASE(AUTO. STEAM OPTION) Model : PA380S Description View : INSIDE (See OVEN BACK) Quantity...
Page 57 SECTION ELECTRIC SCHEMATICS...
Page 58 OVEN 5 A. SWITCH HIGH LIMIT HIGH 140°F LIMIT 110°F COOLING BULB P.L. PROOFER SWITCH 20 A 20 A LIQUID LEVEL PROOFER VALVE ELECTRONIC TIMER COOKING TIMER H5CX (MODE A−1) COOKING SWITCH BUZZER INFINIT SWITCH 40 W BULB 2.5 KW...
Page 59 FOR SUPPLY SYSTEMS CONSISTING OF A DELTA SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). HIGH THERMOSTAT...
Page 60 3/4 HP MOTOR 220 / 380 19A 16.5A 20A TOTAL POWER: & 11.8 Kw HIGH THERMOSTAT LIMIT STEAM STEAM TIMER H3DE SWITCH OVEN VALVE COOKING MODE E SWITCH 1.5 KW PILOT @ 240V LIGHT HEAT PILOT LIGHT HUMIDITY 1.5 KW @ 240V...
Page 61 OVEN 5 A. SWITCH HIGH LIMIT 140° HIGH LIMIT 110° COOLING P.L. ELECTRONIC TIMER THERMOSTAT HIGH LIMIT 500° F COOKING TIMER H5CX (MODE A−1) BULB COOKING SWITCH BUZZER 2.5 KW EACH ELEMENT 3/4HP MOTOR 120 / 208 2.0A 120 / 240 2.0A...
Page 62 OVEN 5 A. SWITCH HIGH LIMIT 140° HIGH LIMIT 110° COOLING P.L. ELECTRONIC TIMER THERMOSTAT HIGH LIMIT 500° F COOKING TIMER H5CX (MODE A−1) BULB COOKING SWITCH BUZZER 2.5 KW EACH ELEMENT 3/4HP MOTOR 120 / 208 2.0A 120 / 240 2.0A...
Page 63 FOR SUPPLY SYSTEMS CONSISTING OF A DELTA SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). 120 / 208 1.5A...
Page 64 FOR SUPPLY SYSTEMS CONSISTING OF A DELTA SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). 120 / 208 1.5A...
Page 65 ELEMENT 3/4HP MOTOR ALTERNATE TRANSFORMER JA6SL 220V 1 PHASE 50 Hz 25/05/04 TOTAL POWER: & 9.5 Kw NONE HIGH LIMIT 500° F STEAM STEAM TIMER H3DE OVEN VALVE MODE E 100VA 240−480V> 120−240V M. FAUCHER 1 / 1 STANDARD JA6RSL_1...
Page 66 3/4HP MOTOR ALTERNATE TRANSFORMER TOTAL POWER: & 9.5 Kw HIGH LIMIT 500° F STEAM STEAM TIMER SWITCH H3DE OVEN VALVE MODE E 100VA 240−480V> 120−240V JA6SLSC 220V 1 PHASE 50 Hz 25/05/04 M. FAUCHER 1 / 1 STANDARD JA6RSC_1 NONE...
Page 67 OVEN SWITCH HIGH LIMIT 140° HIGH LIMIT 120/24V 110° COOLING 60 W BULB P.L. ELECTRONIC TIMER R2−4 DOOR SWITCH 3−32V DC STEAM 1 3−32V DC BUZZER TEMPERATURE & TIMER PROGRAMABLE CONTROL EVENT STEAM2 120 / 208 2.5KW EACH ELEMENT 120 / 240 TOTAL POWER: 10.7 Kw 60 Hz...
Page 68 OVEN SWITCH HIGH LIMIT 140° HIGH LIMIT 120/24V 110° COOLING 60 W BULB P.L. ELECTRONIC TIMER R2−4 DOOR SWITCH 3−32V DC STEAM 1 3−32V DC BUZZER TEMPERATURE & TIMER PROGRAMABLE CONTROL EVENT STEAM2 120 / 208 2.5KW EACH ELEMENT 120 / 240 TOTAL POWER: 10.7 Kw 60 Hz...
Page 69 FOR SUPPLY SYSTEMS CONSISTING OF A DELTA SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). 120 / 208 1.5A 120 / 240 1.5A...
Page 70 FOR SUPPLY SYSTEMS CONSISTING OF A DELTA SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). 120 / 208 1.5A 120 / 240 1.5A...
Page 71 FOR SUPPLY SYSTEMS CONSISTING OF A DELTA SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). 120 / 208 1.5A 120 / 240 1.5A...
Page 72 FOR SUPPLY SYSTEMS CONSISTING OF A DELTA SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). 120 / 208 1.5A 120 / 240 1.5A...
Page 73 120 / 208 100A 103A 120 / 240 TOTAL POWER: & 21.4 Kw OL1−95 OL2−95 26/05/04 NONE OL1−95 STEAM TIMER H3DE OVEN VALVE MODE E OL2−95 OVEN VALVE JA12SL 1 PHASE 60 Hz M. FAUCHER 1 / 1 STANDARD JA12SL_1...
Page 74 3.0A 51.0A 48.0A 58.0A 31/05/04 TOTAL POWER: & 21.4 Kw 2, 4, 9 & 10 OL1−95 STEAM TIMER H3DE OVEN VALVE MODE E OL2−95 STEAM TIMER H3DE OVEN VALVE BLUE BLUE JA12SL 3 PHASES 60 Hz M. FAUCHER 1 / 1 STANDARD JA12SL3R...
Page 75 (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). 31/05/04 NONE OL1−95 STEAM TIMER H3DE OVEN VALVE MODE E OL2−95 OVEN VALVE JA12SL 3 PHASES 50 Hz M. FAUCHER 1 / 1 STANDARD JA12SL3R...
Page 76 3.0A 51.0A 48.0A 58.0A 31/05/04 TOTAL POWER: & 21.4 Kw 2, 4, 9 & 10 OL1−95 STEAM TIMER H3DE OVEN VALVE MODE E OL2−95 STEAM TIMER H3DE OVEN VALVE BLUE BLUE JA12SL 3 PHASES 60 Hz M. FAUCHER 1 / 1 STANDARD JA12SL_3...
Page 77 5 A. SW 1.1 COOKING TIMER H5CX (MODE A−1) THERMOSTAT HIGH LIMIT 110°F BULB COOKING (OVEN 1) SWITCH BUZZER 5 A. SW 2.1 COOKING TIMER THERMOSTAT H5CX (MODE A−1) BULB COOKING (OVEN 2) SWITCH BUZZER PROOFER 5 A. SWITCH 20 A.
Page 78 SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). 120 / 208 73A 67.5A 65.2A 120 / 240 16A 65.5A 60.7A 56.5A...
Page 79 SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). 220 / 380 TOTAL POWER: 20.5 Kw 50 Hz OL1−95...
Page 80 THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). 01/06/04 NONE OL1−95 R2−4 OL2−95 R4−4 JA12SL 3 PHASES 60 Hz M. FAUCHER 1 / 1 WATLOW JA12_3W...
Page 81 SECONDARY TRANSFORMER, MAKE SURE THAT THE PHASE FEEDER WITH THE HIGHEST VOLTAGE (HIGH LEG) IS CONNECTED TO L3 IN THE SUPPLY BOX OF THIS OVEN (120 / 240V. 3 PH. SYSTEMS). JA12SL 3 PHASES 60 Hz 01/06/04 NONE OL1−95 STEAM TIMER...
Page 82: Limited Warranty
LIMITED WARRANTY (Continental United States Of America And Canada Only) Doyon Equipment Inc. guarantees to the original purchaser only that its product are free of defects in material and workmanship, under normal use. This warranty does not cover any light bulbs, thermostat calibration or defects due to or resulting...
