Slide the sun shield according to the arrow direction as shown in Figure 1-7(left).
Tighten the lock screw on the sun shield.
NOTE:
For water-proofing, please align the rotating label on the front cover with that on the camera when you
rotate the front cover clockwise. Refer to Figure 1-7 , above (right).
12000 Pecos St., Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
1
Assemble the Camera
Figure 1-7
V-Series Camera Quick Start Guide | VX-4V-B-RI
Rotating Label
7
