CoolLED pE-300 Series Quick Start Manual

Illumination system

Hide thumbs Also See for pE-300 Series:

pE-300 Series

Quick Start Guide

This guide should provide some basic information on the setup and operation

of the CoolLED pE-300 Series Illumination System.

Before operating this product please read and observe the advice given in the

safety section of the full User Manual.

For more detailed information on the full range of options and functions

please see the full User Manual.

DOC-017 Iss 2

Table of Contents

Need help?

Do you have a question about the pE-300 Series and is the answer not in the manual?

Page 1 Quick Start Guide This guide should provide some basic information on the setup and operation of the CoolLED pE-300 Series Illumination System. Before operating this product please read and observe the advice given in the safety section of the full User Manual.
Page 2 Control Pod Power Supply A typical pE-300 Series order will include the parts shown. A microscope adaptor that was specified when ordering will be fitted to the pE-300 Series Light Source. A mains power cable for the specified region of use shall also be included (not pictured).
Page 3 3. Connecting the Control Pod and power supply Connect the pE- 300 Control Pod cable to the light source. Ensure the correct orientation of the connector by aligning the two red dots. Insert the power supply connector into the Light Source.
Page 4 Control Pod is shown in the image above. The controls available will vary slightly depending on the version of pE-300 Series Illumination System being used. When the system is powered up the Light Source shall be in the “Off” state. Pressing the select buttons will allow you to select or deselect different channels.
Page 5 5. Optical adjustment To optimize the Thumbscrew Light Source set up a sample that Pull post back covers the entire and forth to field of view. make adjustments Loosen the thumbscrew and slide the adjuster back and forth whilst viewing the sample.
