    WTI Part No.: 14055 Rev.: B AFS-16-1 Automated Fallback Switch Quick Start Guide...

  • Page 2: Input Supply

    • Shock Hazard - Do Not Enter Two Power Supply Cables Note that the AFS-16-1 features two separate power inputs, and a separate power supply cable for each power input. Make certain to disconnect both power supply cables from their power source before attempting to service or remove the unit.

  • Page 3: Hardware Installation

    Set the Power Switch on the AFS-16-1 Power Module to the ON Position. The ON LED on the Power Module and the A/B indicators on the Control Module should light.

  • Page 4: Communicating With The Afs-16

    To enable Telnet and/or Web Browser access, please refer to the User's Guide. Notes: • Default AFS-16-1 serial port parameters are set as follows: 9600 bps, RTS/CTS Handshaking, 8 Data Bits, One Stop Bit, No Parity. Although these parameters can be easily redefined, for this Quick Start procedure, it is recommended to configure your communications program to accept the default parameters.

  • Page 5: Fallback Switching - Text Interface

    (Login) and password. The default username is "super" (all lower case, no quotes), and the default password is also "super". If a valid username and password are entered, the AFS-16-1 will display either the Main Menu (Web Browser Interface) or the Circuit Status Screen (SSH, Telnet, or Modem.)

  • Page 6: Fallback Switching - Web Browser Interface

    The Web Browser Interface will not be available until you have enabled Web Access as described in the User's Guide. After Web Access has been enabled, access the AFS-16-1 Web Browser Interface as described in Section 3 in this Quick Start Guide and proceed as follows: Access the Circuit Control Menu: Click on the "Circuit Control"...
  • Page 7 AFS-16: Automatic Fallback Switch; Quick Start Guide Page 7...
  • Page 8 5 Sterling • Irvine • California 92618 (949) 586-9950 • Toll Free: 1-800-854-7226 Fax: (949) 583-9514 • http://www.wti.com...
