Quick Start Guide - Morgana DIGIFOLD Operating Manual

Setting the machine to operate in automatic mode.
1. Set the gap between the paper gate and the vacuum roller to
approximately twice the thickness of the stock to be creased.
(See page 17)
2. Place the stock to be creased onto the loading table against the
fixed side lay. (See page 17)
3. Release the clamps on the adjustable side lay and slide up to the
paper stack allowing a gap of approximately 0.5mm (1/64 inch)
between the paper and the side lay. (See page 17)
4. Place the backstop on to the adjustable side lay and slide up to
the paper stack, also allowing a gap (as stated in the above step)
before clamping. (See page 19)
5. Now follow the step by step instructions shown on page 9.
To manually feed sheets see instructions on page 23.
T o 'Set by Position' see instructions on page 14.
Page 8

Quick Start Guide

(i.e. ,Set by Fold')
CREASING / FOLDING
