AO SERIES | INSTRUCTIONS MANUAL

2.3 Connections

2.3.1 Layout of connectors

Figure 1: view of the AOL0223X connections.
Pinout for the 12-pin Hirose connector
Pin Reference
Figure 2: Top view of the Hirose 12-pin connector for reference pin detection.
RJ45 Connector
Hirose 12-PIN Connector
[ P.N.: HR10G-10R-12PB(71) ]
7
8
6
12
9
5
10
11
1
4
2
3
Connector top view
