AO SERIES | INSTRUCTIONS MANUAL
Part number
Optical specifications
Power (min)
Power (max) (D)
Clear aperture (mm)
Scan rate (Hz)
Transmittance (%)
Electrical specifications
DC voltage (V)
Power consumption max (W)
Operating temperature
Storage temperature
Enviromental
Humidity
IP rating
Installation
Communication
Connector 1
Interfaces 2
I/O signal functions
Mechanical specifications
Mount
Length (mm)
Width (mm)
Height (mm)
Material
Clamping system
Compatibility
Lenses
Cameras
Cable
1 Standard industrial circular connector, for I/O and power connections.
2
Custom protocol, see manual for more information.
AOL0223B
(D) 3.5
0
23
100
>90
24
5
10 to 40
0 to 50
10-85% non condensing
Indoor use only
RJ45, 12-pin Hirose
Ethernet, RS232
Analog control - Digital control - Ready
M30.5x0.5
116
63
27.7
Anodized aluminum, scratch resistant polycarbonate (Lexan Margard®)
6x M3 holes
ENMP series, ENHR series - EN2MP series, EN5MP series
mvBueFOX3-2 series,mvBlueCougar series
CBUSB3001, CBETH003, CBGPIO001
