62 Position Indexer/Speed Profiler
Profile Command Control Word
The profile/indexer is controlled with [Profile Command], parameter 705. The bit
definitions are as follows:
Bit Name Description
0 Start Step 0 The binary value of these bits determines which step will be the starting step
for the profile when a start command is issued. If the value of these bits are not
1 Start Step 1
1-16 the drive will not run since it does not have a valid step to start from. Valid
2 Start Step 2
Examples: 00011 = step 3, 01100 = step 12
3 Start Step 3
4 Start Step 4
5-7 Reserved Not used
8 Hold Step When set, this command will inhibit the profile from transitioning to the next
step when the condition(s) required are satisfied. When the Hold command is
released, the profile will transition to the next step.
9 Pos Redefine This bit is used to set the present position as Home. When this bit is set,
[Profile Status] bit "At Home" will be set and the [Units Traveled] will be set to
zero.
10 Find Home This bit is used to command the Find Home routine.
11 Vel Override When this bit is set the velocity of the present step will be multiplied by the
value in [Vel Override].
12-31 Reserved Not used.
The bits in [Profile Command] can be set via DPI interface (HIM or Comm) or
digital inputs. When digital input(s) are programmed for "Pos Sel 1-5," the starting
step of the profile is exclusively controlled by the digital inputs. The DPI interface
value for bits 0-4 will be ignored.
If a digital input is configured for bit 8-11 functions of the [Profile Command], the
DPI interface or the digital input can activate the command.
Velocity Regulated Step Parameters
Each of the Velocity Regulated steps has the following associated parameters or
functions:
Step Type
Time Time Blend
Value Total Move Total Time
Time
Velocity Speed & Speed &
Direction Direction
Accel Time Accel Rate Accel Rate
Decel Time Decel Rate Decel Rate
Next Step Time Time greater
Condition greater than than [Step
[Step Value] Value]
Dwell Dwell Time X
Batch Batch X
Number
Next Next Step Next Step
X = Function not applicable to this step type
Digital Encoder
Input Incremental Blend
Digital Input Position & Direction Parameter
Number
Speed & Speed
Direction
Accel Rate Accel Rate
Decel Rate Decel Rate
Digital Input At Position [Step
logic Value]
Dwell Time X
Batch X
Number
Next Step Next Step
Parameter
Level End
X
Number ±
Speed & X
Direction
Accel Rate X
Decel Rate Decel Rate
[Step Value] At Zero
> or < [Step transition
Dwell]
Compare Dwell Time
Value
X X
Next Step X (Stop)
