Allen-Bradley PowerFlex Installation Instructions Manual

PowerFlex® DC Drive
Frame D Field Circuit Board
Installation Instructions
What This Kit Includes
Tools That You Need
What You Need to Do
ATTENTION: Only qualified personnel familiar with DC drives
and associated machinery should plan or implement the installation,
start-up and subsequent maintenance of the system. Failure to comply
may result in personal injury and/or equipment damage.
ATTENTION: To avoid an electric shock hazard, ensure that all
power to the drive has been removed before performing the following.
ATTENTION: This drive contains ESD (Electrostatic Discharge)
sensitive parts and assemblies. Static control precautions are required
when installing, testing, servicing or repairing this assembly.
Component damage may result if ESD control procedures are not
followed. If you are not familiar with static control procedures,
reference A-B publication 8000-4.5.2, "Guarding Against
Electrostatic Damage" or any other applicable ESD protection
handbook.
• Field circuit board
• Ribbon cable at connector XFCD
• Cable at connector X3
• Eleven hexalobular screws
• Static strap
• Phillips
®
screwdriver
• Hexalobular screwdriver
®
Phillips is a registered trademark of Phillips Screw Company.
To install the field board:
Step 1: Remove power from the drive
Step 2: Remove the protective covers
Step 3: Remove the existing field board
Step 4: Install the new field board
Step 5: Replace the protective covers and document the change
Publication 20P-IN051A-EN-P
