FourStar 11210533CL Assembly Instructions

MODEL: 11210533CL
6 CUBE ORGANIZER
!
WARNING:
ADULT ASSEMBLY REQUIRED
Keep screws, small parts and plastic
bags out of children's reach during
and after assembly.
STEP 1
INSTALL DOWEL (1) INTO PANEL (B) & (C), AS SHOWN.
INSERT CAM-LOCK NUT (7) INTO THE PRE-DRILLED
HOLES ON PANEL (B) & (C).
INSERT AND SECURE CAM-LOCK SCREW (8) INTO
THE PRE-DRILLED HOLES ON (A) (B) & (C).
INSTALL NAIL LEG (6) WITH HAMMER.
6
UNFINISHED 8
6
8
SURFACE
8
8
A
C
B
8
7
7
1
1
1
1
STEP 6
ATTACH PANEL (E) TO PANEL (C). TIGHTEN
CAM-LOCK NUT (7) USING SCREWDRIVER.
ATTACH PANEL (G) TO PANEL (E) WITH DOWEL (2),
AS SHOWN.
COVER CAM LOCK WITH COVER STICKER (9).
7
FINISHED EDGE
C
2
G
FINISHED
G
EDGE
E
F
BEFORE YOU BEGIN, PLEASE READ ASSEMBLY INSTRUCTIONS
CAREFULLY. FOLLOW THEM STEP BY STEP.
CAUTION:
1. ADULT SUPERVISION IS REQUIRED DUE TO SMALL PARTS.
CARE SHOULD BE TAKEN IN THE UNPACKING
AND ASSEMBLY OF THE PRODUCT.
2. ASSEMBLE ON SOFT SURFACES TO PREVENT
DAMAGE TO THE PRODUCT FINISH.
3. MAKE SURE ALL PARTS ARE INCLUDED BEFORE ASSEMBLY.
ASSEMBLY TOOLS REQUIRED
PHILIPS SCREWDRIVER
HAMMER
Do you have any questions? Missing small parts or hardware? If you need
6 CUBE ORGANIZER
assistance with the assembly of your
support@fourstari.com or
please e-mail our Customer Service Department at:
call us at (800) 639-3803 or (508) 473-7688
from Massachusetts area
Please include the following information in your email:
• Where item was purchased • Item, model, style or SKU number listed on
instructions or box • Part number, description of the part and quantity needed
This information will help us get the proper part to you faster
STEP 2
INSTALL DOWEL (1) INTO PANEL (D) (E) (F), AS
SHOWN.
INSERT CAM-LOCK NUT (7) INTO THE PRE-DRILLED
HOLES ON PANEL (E) & (F).
1
1
D
6
8 1
6 UNFINISHED
7 SURFACE
1
1
E
1
F
7
7
1
1
8
1
1
STEP 7
ATTACH PANEL (D) TO PANEL (C).
ATTACH PANEL (G) TO PANEL (D) WITH DOWEL (2),
AS SHOWN.
FINISHED EDGE
G
2 C
FINISHED
EDGE G
D
G
9
E
F
PARTS AND HARDWARE LIST
NO PARTS LIST
A TOP PANEL
B LEFT SIDE PANEL
C RIGHT SIDE PANEL
D SECOND SHELF PANEL
E THIRD SHELF PANEL
F BOTTOM PANEL
if calling locally
G CENTER PANEL
H SKIRT PANEL
I BACK PANEL
STEP 3
TIGHTEN BRACKET (4) TO PANEL (H) WITH
SCREW (3).
UNFINISHED
3
SURFACE
1 4
7
1
H
3
4
3
STEP 8
ATTACH PANEL (B) TO ASSEMBLED UNIT. TIGHTEN
CAM-LOCK NUT (7) USING SCREWDRIVER.
COVER CAM LOCK WITH COVER STICKER (9).
C
FINISHED EDGE
G
G
G
B
7
F
9
QTY NO HARDWARE LIST
1 PC 1 SHORT PLASTIC DOWEL 20 PCS
1 PC 2 LONG PLASTIC DOWEL
1 PC 3 SCREW
1 PC 4 L-BRACKET
1 PC 5 POWER PIN 30 PCS
1 PC 6 NAIL LEG
3 PCS 7 CAM-LOCK NUT
1 PC 8 CAM-LOCK SCREW
3 PCS 9 COVER STICKER
STEP 4 STEP 5
REINFORCE PANEL (H) TO PANEL (H) WITH ATTACH PANEL (F) TO PANEL (C). TIGHTEN
SCREW (3). CAM-LOCK NUT (7) USING SCREWDRIVER.
ATTACH PANEL (G) TO PANEL (F) WITH DOWEL
(1), AS SHOWN.
COVER CAM LOCK WITH COVER STICKER (9).
3
UNFINISHED
SURFACE FINISHED
EDGE
H
3
F
3
STEP 10
ATTACH PANEL (I) TO THE BACK
POSITION OF STORAGE WITH POWER PIN (5).
STEP 9
ATTACH PANEL (A) TO ASSEMBLED UNIT WITH
DOWEL (1), AS SHOWN.
TIGHTEN CAM-LOCK NUT (7) USING SCREWDRIVER.
COVER CAM LOCK WITH COVER STICKER (9).
UNFINISHED SURFACE
FINISHED EDGE
A
1
G 7
D
E
C
B
F
9
I
I
QTY
A
I
4 PCS
D
G
4 PCS
C
2 PCS
E
G
B
4 PCS
F
G
6 PCS
6 PCS
H
6 PCS
FINISHED EDGE
7
C
G
9
1
F
UNFINISHED
SURFACE
A
5
5
5
I
I
B
I
5
5
5
5
5
5
