FourStar 11211851WM Assembly Instructions

ENTERTAINMENT CENTER
CAUTION :
1. ADULT SUPERVISION IS REQUIRED DUE TO SMALL PARTS.
CARE SHOULD BE TAKEN IN THE UNPACKING AND
ASSEMBLY OF THE PRODUCT.
2. ASSEMBLE ON SOFT SURFACES TO PREVENT DAMAGE TO
THE PRODUCT FINISH.
3. MAKE SURE ALL PARTS ARE INCLUDED BEFORE ASSEMBLY.
Do you have any questions? Missing small parts or hardware? If you need
assistance with the assembly of your ENTERTAINMENT CENTER please e-mail
our Customer Service Department at:
call us at (800) 639-3803 or (508) 473-7688
from Massachusetts area
Please include the following information in your email:
• Where item was purchased • Item, model, style or SKU number listed on
instructions or box • Part number, description of the part and quantity needed
This information will help us get the proper part to you faster

STEP 1

PLACE THE TOP PANEL (A), LEFT TOP
PANEL (B) & RIGHT TOP PANEL (C)
SURFACE FACE DOWN.
THEN PLACE THE INSERT CAPS (3)
FIRMLY INTO THE OPENINGS, TAP
LIGHTLY WITH A HAMMER JUST
ENOUGH FOR THE INSERTS TO REMAIN
TIGHTLY IN THE OPENING.
INSERT CAP
CASQUILLO INSERTABLE
A
C

STEP 4.

ATTACH CENTER PANEL (D) AND 4 SHORT TUBES (2) TO
ASSEMBLED STEP 3 AS SHOWN.
2
C
MODEL: 11211851WM
support@fourstari.com or

STEP 2.

CAREFULLY ATTACH THE SHORT
TUBES (2) TO THE INSERT CAPS (3) OF
TOP PANEL (A).
INSERT CAP
2
CASQUILLO INSERTABLE
B
D
B
A
BEFORE YOU BEGIN, PLEASE READ ASSEMBLY
INSTRUCTIONS CAREFULLY. FOLLOW THEM
STEP BY STEP.
NO
A
B
C
D
E
NO
1
if calling locally
2
3
4
5
A

STEP 5.

ATTACH BOTTOM PANEL (E), LEG (4) AND DUCK LEG (5)
TO ASSEMBLED STEP 4 AS SHOWN.
This unit is intended for use only
with the products and maximum
weights indicated. Use with other
products or products heavier than
the maximum weights indicated may
result in instability causing possible
injury. Furniture can tip over or break
if improperly moved. Have a friend
help to lift and carry the unit to its
new location.

PARTS LIST

TOP PANEL
LEFT TOP PANEL
RIGHT TOP PANEL
CENTER PANEL
BOTTOM SIDE PANEL

HARDWARE LIST

LONG PE TUBE
SHORT PE TUBE
PE INSERT CAP
PE LEG
PE DUCK LEG

STEP 3

ATTACH LEFT TOP PANEL (B) & RIGHT
TOP PANEL (C), AND 4 SHORT TUBES (2)
TO ASSEMBLED STEP 2 AS SHOWN.
AND ATTACH LONG TUBES (1) TO LEFT
TOP PANEL (B) & RIGHT TOP PANEL (C).
1
2
C
A
E
4
5
E
D
B
A
C
135 lbs. (61.2 kg)
18 lbs. (8.16 kg)
75 lbs. (34 kg)
18 lbs. (8.16 kg)
QTY
1 PC
1 PC
1 PC
1 PC
2 PCS
QTY
2 PCS
12 PCS
6 PCS
4 PCS
2 PCS
B
18 lbs.
(8.16 kg)
18 lbs.
(8.16 kg)
