FourStar 11210918A Assembly Instructions

MODEL: 11210918A
8 DRAWER ORGANIZER

STEP 1

1.1 INSERT WOODEN DOWEL (3) TO SIDE PANEL (B) WITH GLUE (10).
1.2 INSERT PLASTIC DOWEL (4) TO CENTER PANEL (D) WITH
GLUE (10).
3
10
4
D x 4
B x 2
3 WOODEN DOWEL - 4 PCS
4 PLASTIC DOWEL - 16 PCS

STEP 5

5.1 TIGHTEN WITH SCREW (1) TO SIDE PANEL (B), SHELF PANEL (C)
AND BOTTOM PANEL (E).
5.2 INSTALL NAIL LEG (7) TO THE BOTTOM OF SIDE PANEL (B)
WITH HAMMER.
B
C
C
C
B
E
1 M4 x 32mm CHIPBOARD SCREW - 16 PCS
7 NAIL LEG - 4PCS

CAUTION :

1. ADULT SUPERVISION IS REQUIRED DUE TO SMALL PARTS.
CARE SHOULD BE TAKEN IN THE UNPACKING AND
ASSEMBLY OF THE PRODUCT.
2. ASSEMBLE ON SOFT SURFACES TO PREVENT DAMAGE TO
THE PRODUCT FINISH.
3. MAKE SURE ALL PARTS ARE INCLUDED BEFORE ASSEMBLY.
BEFORE YOU BEGIN, PLEASE READ ASSEMBLY INSTRUCTIONS
CAREFULLY. FOLLOW THEM STEP BY STEP.

ASSEMBLY TOOLS REQUIRED

RUBBER MALLET
PHILIPS SCREWDRIVER
Do you have any questions? Missing small parts or hardware? If you need
assistance with the assembly of your 8 DRAWER ORGANIZER please e-mail our
support@fourstari.com or
Customer Service Department at:
call us at (800) 639-3803 or (508) 435-4830
if calling locally
from Massachusetts area
Please include the following information in your email:
• Where item was purchased • Item, model, style or SKU number listed on
instructions or box • Part number, description of the part and quantity needed
This information will help us get the proper part to you faster

STEP 2

2.1 INSTALL L-BRACKET (6) WITH SCREW (2) TO SKIT PANEL (F).
**FOLLOW THE MARKING**
2.2 ATTACH SKIT PANEL (F) TO BOTTOM PANEL (E) WITH SCREW (2).
TIGHTEN THE L-BRACKET (6).
F
F
E
2 M3 x 9mm CHIPBOARD SCREW - 4 PCS
6 L - BRACKET - 2 PCS

STEP 6

ATTACH BACK PANEL (G) TO THE REAR POSITION OF STORAGE
WITH POWER PIN (5), AS SHOWN.
G
G
5 POWER PIN - 18PCS

PARTS LIST AND HARDWARE

NO HARDWARE LIST
1 M4 x 32mm CHIPBOARD SCREW
2 M3 x 9mm CHIPBOARD SCREW
3 WOODEN DOWEL
4 PLASTIC DOWEL
5 POWER PIN
6 L-BRACKET
7 NAIL LEG
8 BIG NON-WOOVEN BIN
9 SMALL NON-WOOVEN BIN
10 WHITE GLUE

STEP 3

ATTACH CENTER PANEL (D) TO THE PANEL (A)(C)(E) WITH
GLUE (10).
D
A
C
D
C D
C
D
10

STEP 7

UNFOLD THE BIN (8)(9) AND SLIDE IT IN THE STORAGE.
9
8
QTY
NO PARTS LIST
16 PCS
A TOP PANEL
4 PCS
B SIDE PANEL
4 PCS
16 PCS C SHELF PANEL
18 PCS
D CENTER PANEL
2 PCS
E BOTTOM PANEL
4 PCS
4 PCS
F SKIT PANEL
4 PCS
G BACK PANEL
1 PC

STEP 4

ATTACH SIDE PANEL (B) TO ASSEMBLED OF STEP 3 WITH
GLUE (10).
D
A
D
C
D
C
C
B
10
E
This unit is intended for use only with the products and maximum weights
indicated. Use with other products or products heavier than the maximum
weights indicated may result in instability causing possible injury.
Furniture can tip over or break if improperly moved. Have a friend help
to lift and carry the unit to its new location.

Weight limit:

58.5 lbs. (26.5kg)
QTY
1 PC
2 PCS
3 PCS
4 PCS
1 PC
1 PC
2 PCS
