FourStar 11224668 Assembly Instructions

MODEL: 11224668
"A" FRAME DESK

STEP 1

STEP 1-1

INSERT BRACKET (6) INTO PANEL (F) BY USING RUBBER
MALLET.

STEP 1-2

INSERT WOODEN DOWEL (5) INTO PANEL (B) (C).
F
5
6
C
B

STEP 5

ATTACH PANEL (E), SQUARE LEG (2) AND PANEL (G) TO ASSEMBLED PART
AND SECURE BY USING SCREW (4).
G
E
2
D
A
BEFORE YOU BEGIN, PLEASE READ ASSEMBLY INSTRUCTIONS
CAREFULLY. FOLLOW THEM STEP BY STEP.
CAUTION:
1. ADULT SUPERVISION IS REQUIRED DUE TO SMALL PARTS.
CARE SHOULD BE TAKEN IN THE UNPACKING
AND ASSEMBLY OF THE PRODUCT.
2. ASSEMBLE ON SOFT SURFACES TO PREVENT
DAMAGE TO THE PRODUCT FINISH.
3. MAKE SURE ALL PARTS ARE INCLUDED BEFORE ASSEMBLY.

ASSEMBLY TOOLS REQUIRED

RUBBER MALLET
Do you have any questions? Missing small parts or hardware? If you need
"A" FRAME DESK
assistance with the assembly of your
support@fourstari.com or
please e-mail our Customer Service Department at:
call us at (800) 639-3803 or (508) 473-7688
if calling locally
from Massachusetts area
Please include the following information in your email:
• Where item was purchased • Item, model, style or SKU number listed on
instructions or box • Part number, description of the part and quantity needed
This information will help us get the proper part to you faster

STEP 2

INSTALL INSERT CAP (3) INTO PANEL (A) BY USING
RUBBER MALLET.
3
A

STEP 6

ATTACH PANEL (B) TO ASSEMBLED PART AND SECURE BY USING SCREW (4).
4
4

PARTS AND HARDWARE LIST

NO HARDWARE LIST QTY NO
1 LONG SQUARE TUBE 4 PCS A TOP PANEL
2 PCS
2 PE SQUARE LEG B LEFT SIDE PANEL
PE INSERT CAP 2 PCS C RICHT SIDE PANEL
3
M4 x 45MM C/B
10 PCS
4 D CENTER PANEL
SCREW(BLACK)
M5 x 25MM
8 PCS
5 E BOTTOM PANEL
WOODEN DOWEL
2 PCS
6 45MM BRACKET F APRON PANEL
4 PCS
7 #8 x l" CSK SCREW G BACK PANEL
PE SCREW CAP
6 PCS
8
COVER (BLACK)

STEP 3

ATTACH LONG SQUARE TUBE (1) TO PANEL (A) AND
TIGHTEN IT.
1
A

STEP 7

STEP 7-1
SECURE PANEL (F) TO PANEL (E) BY ATTACHING SCREW (7) TO BRACKET
ON PANEL (F).
G
STEP 7-2
COVER SCREW HOLES BY SCREW CAP COVER (8).
E
C
D
A
B
PARTS LIST QTY
1 PC
1 PC
1 PC
1
1 PC
B
G
1 PC
1
1 PC
1 PC

STEP 4

STEP 4-1

ATTACH LONG SQUARE TUBE (1) AND PANEL (D) TO
ASSEMBLED PART.
STEP 4-2
ATTACH PANEL (C) TO PANEL(D) AND ATTACH PANEL (F)
TO PANEL (C) BY USING SCREW (4).
1
D
F
A
6
E
7
D
A
A
D
1
C
E
C
4
8
