FastMile Home Outdoor Modem User Manual
3 Installation Procedure
This chapter describes the pre-requisites for Home Outdoor Modem Installation. The chapter
also guides us with the step by step installation procedure along with the dependencies on
each step.
3.1 Safety Information
•
Professional installation is recommended for Home Outdoor Modem. If the user plans to
install the Home Outdoor Modem himself, safety instructions should be take care of.
•
Use only FastMile Home Router or Nokia approved PoE Injectors for powering the Home
Outdoor Modem.
•
Do not POWER ON the Home Outdoor Modem before assembling the entire setup.
•
Maintain at least 50 cm distance from the front face of the Home Outdoor Modem while
the system is operating.
•
Install at a minimum height of 2.5 meters from the ground plane
•
WARNING: Lightning Danger: Since cables from external environment may connect to
the system and they are exposed to lightning, do not work on equipment or cables during
periods of lightning activity.
3.2 Package Contents
Sales Item No
1
2
3
4
Table 7
Package contents of Home Outdoor Modem
Note: If one or more item(s) mentioned above is missing or damaged, please contact
customer support.
3.3 Home Outdoor Modem Installation Prerequisites
•
Installation person should have the knowledge on installing the Unit.
•
Valid SIM needs to be inserted in the Home Outdoor Modem before mounting to the pole
or wall.
•
All the devices should be available and registered on operator's Point of Sales location.
•
Mechanical tools are required (not included) for mounting the Home Outdoor Modem.
Release 17.10
DN09218237, Issue 03 Draft
28.11.2017
Item
Home Outdoor Modem Unit
Ethernet Adapter
Wall Mounting Anchor
Pole Mounting Anchor (Optional)
© 2017 Nokia
Installation Procedure
Quantity
1
1
1
1
15
