Process Remote I/O (RIO) Communication
Interface Module
Catalog Number 1757-ABRIO
Topic
About This Publication
Use this publication as a guide to install the Process Remote I/O (RIO)
Communication Interface Module. Refer to publication 1757-UM007C, the
1757-ABRIO User Manual, for additional information. You can download a
.pdf file of the manual at: http://literature.rockwellautomation.com.
Installation Instructions
Page
2
3
4
5
5
6
6
7
8
9
10
11
12
13
15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1757-ABRIO and is the answer not in the manual?

Questions and answers

Related Manuals for Allen-Bradley 1757-ABRIO

Summary of Contents for Allen-Bradley 1757-ABRIO

  • Page 1: Table Of Contents

    About This Publication Use this publication as a guide to install the Process Remote I/O (RIO) Communication Interface Module. Refer to publication 1757-UM007C, the 1757-ABRIO User Manual, for additional information. You can download a .pdf file of the manual at: http://literature.rockwellautomation.com.

  • Page 2: Important User Information

    2 Process Remote I/O (RIO) Communication Interface Module Important User Information Solid state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://literature.rockwellautomation.com) describes some important differences between solid state equipment and hard-wired electromechanical devices.

  • Page 3: Environment And Enclosure

    In addition to this publication, see: • Industrial Automation Wiring and Grounding Guidelines, for additional installation requirements, Allen-Bradley publication 1770-4.1. • NEMA Standards publication 250 and IEC publication 60529, as applicable, for explanations of the degrees of protection provided by different types of enclosure.

  • Page 4: North American Hazardous Location Approval

    4 Process Remote I/O (RIO) Communication Interface Module North American Hazardous Location Approval The following information applies Informations sur l'utilisation de cet when operating this equipment in équipement en environnements hazardous locations. dangereux. Products marked “CL I, DIV 2, GP A, B, C, D” are Les produits marqués “CL I, DIV 2, GP A, B, C, D”...

  • Page 5: Prevent Electrostatic Discharge

    Process Remote I/O (RIO) Communication Interface Module 5 Prevent Electrostatic Discharge This equipment is sensitive to electrostatic discharge, which can ATTENTION cause internal damage and affect normal operation. Follow these guidelines when you handle this equipment: • Touch a grounded object to discharge potential static. •...

  • Page 6: Prepare The Chassis For Module Installation

    6 Process Remote I/O (RIO) Communication Interface Module Prepare the Chassis for Module Installation Before you install the 1757-ABRIO module, you must install and connect a ProcessLogix or ControlLogix chassis and power supply. Determine Module Slot Location Chassis slots are numbered starting from the left, starting at 0. Slot 0 is the first slot to the right of the power supply.

  • Page 7: Install The Module

    Process Remote I/O (RIO) Communication Interface Module 7 Install the Module Do not force the module into the backplane connector. If you cannot ATTENTION seat the module with firm pressure, check the alignment. Forcing the module into the chassis can damage the backplane connector or the module.

  • Page 8: Wire The Connector For The Remote I/O Network

    1. Connect Line 1 of the remote I/O cable to the upper pin. 2. Connect the shield to the middle pin. 3. Connect Line 2 to the lower pin on the 1757-ABRIO. 4. Terminate both ends of a remote I/O network by using external resistors attached to the physical ends of the network.

  • Page 9: Status Display Power-Up Messages

    Boot Next stage in power-up sequence 57ABRIO Ver x.xx.xx Module firmware version If the indicator on the 1757-ABRIO module does not cycle through these messages on powerup, refer to the Troubleshooting section of publication 1757-UM007C, the 1757-ABRIO User Manual. Publication...

  • Page 10: Interpret The Alphanumeric Display

    10 Process Remote I/O (RIO) Communication Interface Module Power Supply Indicator POWER Indicator Power Supply Status Recommended Action • Turn power switch ON. Not operating • Check power wiring connections. • Check fuse. Operating None, normal operation. Interpret the Alphanumeric Display The Process Remote I/O (RIO) Communication Interface Module displays alphanumeric messages that provide diagnostic information about your module.

  • Page 11: Interpret The Status Indicators

    Process Remote I/O (RIO) Communication Interface Module 11 Message Description Error: Heard Another master has been detected on the network because of the Another RIO following possible reasons. • The module is connected to a network with another RIO master. Master •...

  • Page 12: Configuring The Module

    Tech Support, if you need to call for help. Configuring the Module Now that you have installed your 1757-ABRIO module, you must configure it. Refer to publication 1757-UM007C, the 1757-ABRIO User Manual, for information on module configuration.

  • Page 13: Specifications

    Process Remote I/O (RIO) Communication Interface Module 13 Specifications Process Remote I/O (RIO) Communication Interface Module - 1757-ABRIO Attribute Value Module Location ProcessLogix or ControlLogix chassis Backplane Current 675 mA @ +5.1V dc 5 mA @ 24 V dc Power dissipation, max...
  • Page 14 14 Process Remote I/O (RIO) Communication Interface Module Environmental Specifications Attribute Value Emissions CISPR 11: Group 1, Class A ESD immunity IEC 61000-4-2: 6 kV contact discharges 8 kV air discharges Radiated RF IEC 61000-4-3 immunity 10V/m with 1 kHz sine-wave 80%AM from 80 MHz to 2000 MHz 10V/m with 200 Hz 50% Pulse 100%AM at 900 Mhz EFT/B immunity IEC 61000-4-4:...

  • Page 15: Additional Resources

    Automation products. Resource Description Refer to publication 1757-UM007C, the Provides details about how to configure, 1757-ABRIO User Manual for information on access data, monitor and troubleshoot the module configuration. module. Industrial Automation Wiring and Grounding Provides general guidelines for installing a Guidelines, publication 1770-4.1...
  • Page 16 Outside United States Please contact your local Rockwell Automation representative for the return procedure. Allen-Bradley, ProcessLogix, and ControlLogix, RSLinx, RSLinx OEM, RSNetWorx, and TechConnect are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies.
