Startup Options

Desktop Access

Software Support

Software
FactoryTalk Machine Edition Station
FactoryTalk View Studio
for Machine Edition
FactoryTalk ViewPoint
Windows CE 6.0 operating system
You can configure your terminal to perform one of three actions at startup:
• Launch a FactoryTalk View Machine Edition HMI application
• Launch the FactoryTalk View Machine Edition Configuration mode of
the terminal where you load and run applications, configure startup
options and terminal settings, and enable or disable desktop access.
• Launch the Windows Explorer desktop shell. The system is configurable
via the control panel and supports Windows operations.
The factory default state and the startup option following a firmware upgrade is
to launch the FactoryTalk View ME Station Configuration mode of the terminal.
Refer to Startup Options on page 47
startup option.
Any of the terminals can be configured to allow or restrict desktop access. From
the desktop, you can perform system and control panel operations, or run third-
party applications. Terminals with optional, extended features can additionally
run viewers, media players, and launch the web browser. You can even allow access
temporarily to perform specific tasks, then disable desktop access to prevent
unauthorized changes.
TIP
Refer to Desktop Access on page 50
IMPORTANT
All PanelView Plus 6 terminals support the same HMI software.
Table 2 - PanelView Plus 6 Software Support
Description
Runtime environment for FactoryTalk View Machine Edition .mer applications. Machine
Edition Station is preloaded on each PanelView Plus 6 terminal and does not require
FactoryTalk View activation.
Configuration software for developing and testing HMI applications that run on PanelView
Plus 6 terminals preloaded with FactoryTalk View Machine Edition Station.
Add-on capability provided with FactoryTalk View Studio software.
• This web-based, thin-client solution allows manufacturers or casual users to monitor or
download changes to a running Machine Edition application from remote locations via an
Internet browser.
• A single license is embedded with each PanelView Plus 6 terminal supporting a single
client connection to terminal. No additional software is required.
All PanelView Plus 6 terminals and logic modules support the Windows CE 6.0 operating
system with or without optional, extended features.
Rockwell Automation Publication 2711P-UM006A-EN-P - November 2010
for information on how to change the
All terminals are initially shipped with desktop access disabled.
for details on how to modify desktop access.
Allowing desktop access does not change the feature set of your
terminal. For example, If you have a PanelView Plus 6 terminal without
extended features, opening the desktop will not give you access to them.
Overview Chapter 1
Version
6.0 or later
6.0 or later
1.2 or later
6.0 R3
13
