Installation Instructions
Original Instructions
PanelView Plus 700 to 1500 and PanelView
Plus Compact 1000 Terminals and Display
Modules
Catalog Numbers 2711P-Kxxxx, 2711P-Txxxx, 2711P-Bxxxx, 2711P-RDxxxx, 2711PC-
T10C4D1
Topic
Summary of Changes
This document contains new and updated information as indicated in the following table.
Topic
Updated the Attention note in the section titled External Power Supply for Nonisolated DC Terminals and in the
section titled External Power for Isolated DC Terminals.
Page
1
2
3
5
8
9
10
10
11
17
21
23
25
29
31
Page
18
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allen-Bradley PanelView 2711P-RW1
Summary of Contents for Allen-Bradley PanelView 2711P-RW1
-
Page 1: Table Of Contents
Installation Instructions Original Instructions PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Catalog Numbers 2711P-Kxxxx, 2711P-Txxxx, 2711P-Bxxxx, 2711P-RDxxxx, 2711PC- T10C4D1 Topic Page Summary of Changes Important User Information About This Publication Hazardous Locations Wiring and Safety Guidelines About the PanelView Plus 700 to 1500 Terminals Parts List Required Tools... -
Page 2: Important User Information
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Important User Information Read this document and the documents listed in the additional resources section about installation, configuration, and operation of this equipment before you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards. -
Page 3: About This Publication
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules About This Publication This document provides instructions on how to install these devices in a panel. • Factory-assembled PanelView™ Plus or PanelView Plus CE 700 to 1500 terminals •... - Page 4 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Environment and Enclosure This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in IEC publication 60664-1), at altitudes up to 2000 m (6561 ft) without derating.
-
Page 5: Hazardous Locations
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Hazardous Locations This equipment is suitable for these locations: • Class I, Division 2 Groups A, B, C, D • Class II, Division 2 Groups F, G •... - Page 6 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Environnements dangereux Cet équipement ne peut être utilisé que dans les environnements suivants: • Classe I, Division 2, Groupes A, B, C, D • Classe II, Division 2, Groupes F, G •...
- Page 7 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules USB Ports All PanelView Plus and PanelView Plus Compact terminals contain universal serial bus (USB) ports that comply with hazardous location environments. This section details the field-wiring compliance requirements and is provided in accordance with the National Electrical Code, article 500.
-
Page 8: Wiring And Safety Guidelines
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Application Information Per the National Electrical Code the circuit parameters of nonincendive field wiring apparatus for use in hazardous locations shall be coordinated with the associated nonincendive field wiring apparatus such that their combination remains nonincendive. -
Page 9: About The Panelview Plus 700 To 1500 Terminals
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules • Route incoming power to the device by a separate path from the communication lines. • Cross power and communication lines at right angles if they must cross. •... -
Page 10: Parts List
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules About the PanelView Plus Compact 1000 Terminal The PanelView Plus Compact 1000 terminal has a fixed configuration. It does not support communication modules, or the replacement of the logic module. The 1000 terminal contains a non-isolated DC power supply. -
Page 11: Install The Terminal
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Install the Terminal Before installing the terminal in a panel, review the following topics: • Mounting clearances • Panel cutout dimensions • Product dimensions Mounting Clearances Allow adequate clearance around the terminal, inside the enclosure, for adequate ventilation. - Page 12 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Mount the Terminal in a Panel Mounting clips secure the terminal to the panel. The number of clips you use (4, 6, or 8) varies by terminal type. Disconnect all electrical power from the panel before making the panel cutout.
- Page 13 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules 5. Slide the ends of the mounting clips into the slots on the terminal. Mounting Clip Mounting Clip Slot 6. Tighten the mounting clip screws by hand until the gasket seal contacts the mounting surface uniformly.
- Page 14 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Product Dimensions The table provides product dimensions for the terminals including depth dimensions for the: • base configured unit (display module and logic module). • base configured unit with communication module. Width, Height, Approx., Terminal Type...
- Page 15 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules 1000 Terminal Dimensions Keypad or Keypad & Touch 248 (9.77) 399 (15.72) a 55 (2.18) Display to Logic Module b 83 (3.27) Display to Comm Module Touch Screen 248 (9.77) 329 (12.97)
- Page 16 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Ethernet Wiring Use Belden 7921A shielded Ethernet Category 5e cable according to TIA 568-B.1 and RJ45 connector according to IEC 60603-7 for compliance with Marine emissions limits and European Union 89/336/EEC EMC Directive.
-
Page 17: Dc Power Connections
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Follow these steps to remove the terminal block. 1. Loosen the two screws that secure the terminal block. 2. Gently pull the terminal block away from the connector. 3-position AC or DC 2-position DC Terminal Block (series Terminal Block... - Page 18 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules External Power Supply For Non-isolated DC Terminals To identify non-isolated DC logic modules refer to the PanelView Plus Terminals User Manual, publication 2711P-UM001. Use a single, 24V DC power supply to power each PanelView Plus device, such as catalog number 2711P-RSACDIN.
- Page 19 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Earth/Ground Connection PanelView Plus devices with a DC power input have a earth/ground terminal that you must connect to a low-impedance earth/ground. The earth/ground connection is on the rear of the display module.
- Page 20 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Connect DC Power Explosion Hazard - Do not disconnect equipment unless power has been switched off and area is known to be nonhazardous. Disconnect all power before installing or replacing components. Failure to disconnect power may result in electrical shock or damage to the terminal.
-
Page 21: Ac Power Connections
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules AC Power Connections PanelView Plus devices with an integrated AC power supply have these power ratings: • 85…264V AC (47…63 Hz) • 160V A max The input power terminal block supports these wire sizes. Wire Specifications for AC Input Power Terminal Block Dual-wire Single-wire... - Page 22 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Connect AC Power Explosion Hazard - Do not connect or disconnect equipment while circuit is live unless area is known to be nonhazardous. Disconnect all power before installing or replacing components. Failure to disconnect power may result in electrical shock and/or damage to the terminal.
-
Page 23: Battery Precautions
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Battery Precautions When you connect or disconnect the battery an electrical arc can occur. This could cause an explosion in hazardous location installations. Be sure that power is removed and the area is nonhazardous before proceeding. - Page 24 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules 6. Locate the battery on the circuit board. Lift up the edge of the battery indicated by the arrow. 7. Remove the battery by lifting up the side of the battery. 8.
-
Page 25: Troubleshooting
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules 12. Reattach the communication module, if necessary, and tighten the four screws to a torque of 0.58 N•m (5…7 lb•in) This product contains a hermetically sealed lithium battery which may need to be replaced during the life of the product. - Page 26 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules The table shows indicator states if the terminal powers on and stops during startup. Indicator States If the Terminal Stops During Startup Fault (Red) Comm (Green) Description Indicator Indicator...
- Page 27 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Startup Information Messages Startup information messages display in a specific sequence on the terminal during startup and typically display for a few seconds. These messages do not require that you perform any action. Message # Message Description...
- Page 28 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Startup Error Messages When an error occurs, the terminal displays an error number with a text message. The word ERROR! appears under the message in different languages. # Displayed Message ERROR! FEHLER! ERREUR! ERRORE! Error #...
-
Page 29: Specifications
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Specifications PanelView Plus Terminals - 2711P-Kxxxx, 2711P-Txxxx, 2711P-Bxxxx, 2711P-RDxxxx, 2711PC- Txxxx Attribute Value Display Color active matrix, thin film transistor (TFT), liquid crystal display Display type (LCD) Display size 6.5 in. - Page 30 PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules PanelView Plus Terminals - 2711P-Kxxxx, 2711P-Txxxx, 2711P-Bxxxx, 2711P-RDxxxx, 2711PC- Txxxx Weight, Approx for base configured unit without communication module 700 keypad, or keypad and touch 1.9 kg (4.2 lb) 700 touch 1.7 kg (3.8 lb) 1000 keypad, or keypad and touch...
-
Page 31: Additional Resources
PanelView Plus 700 to 1500 and PanelView Plus Compact 1000 Terminals and Display Modules Certifications Certification UL Listed Industrial Control Equipment, certified for use in US and Canada. See File E10314. UL Listed Industrial Control Equipment for use in: c-UL-us •... - Page 32 Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page. Allen-Bradley, FactoryTalk View, PanelView, PanelView Plus, Rockwell Automation, and Rockwell Software are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies.
