Full-Serve Configuration
THE FOLLOWING PROCEDURES DO NOT APPLY TO THE SELF-
SERVE MODEL CONFIGURED FOR PAYMENT. PLEASE REFER TO THE
NEXT SECTION FOR INFORMATION ON SETTING UP THE PAYMENT
COMPONENTS.
Once the machine has been setup and placed in its final operating location,
configuration consists of two final steps.
1. Configure the automatic
shutoff feature and the
delay timer using the
Dip Switches located
inside of the control box.
Manufacturer highly
recommends a delay of
5-10 seconds between 3-4
minute cycles. See Page
11 for a chart with the Dip
settings.
WARNING!: Running multiple cycles repeatedly without allowing the
machine time to drain will result in damage to vacuum motor(s) not
covered by the warranty.
2. Circuit breaker switch to
"ON". Press the red reset
button to ensure circuit is
closed.
Automatic Shutoff Dip Switch Settings
Delay Time (MM:SS)
00:05
00:10
12
SW 7 SW 8
OFF OFF
OFF

Automatic Shutoff Dip Switch Settings
Run Time
SW 1 SW 2
(MM:SS)
01:00 OFF OFF
01:30 OFF

02:00 OFF

02:30
 
03:00 OFF OFF
03:30 OFF

04:00 OFF

04:30
 
05:00 OFF OFF
05:30 OFF

06:00 OFF

06:30
 
07:00 OFF OFF
07:30 OFF

08:00 OFF

08:30
 
09:00 OFF OFF
09:30 OFF

10:00 OFF

12:00
 
15:00 OFF OFF
18:00 OFF

20:00 OFF

25:00
 
30:00 OFF OFF
35:00 OFF

40:00 OFF

00:10
 
00:20 OFF OFF
00:30 OFF

00:40 OFF

00:50
 
